ABB ASL12-30-01-81 24VDC
Brand:
Series:
ASL
Main Contacts:
3NO
Control Circuit:
DC
Control Coil Voltage:
24VDC
Auxiliary Contacts:
1NC
Rated Current:
12A
Poles:
3P
Rated Voltage:
400VAC
Model:
ASL12-30-01-81 24VDC
Order Number:
10083446
Description:
ABB AC contactor ASL12-30-01-81 24VDC, auxiliary contact 1NC, pole number 3P, control circuit DC, main contact 3NO, 400VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | ABB | |
| Series： | ASL | |
| Main Contacts： | 3NO | |
| Control Circuit： | DC | |
| Control Coil Voltage： | 24VDC | |
| Auxiliary Contacts： | 1NC | |
| Rated Current： | 12A | |
| Poles： | 3P | |
| Rated Voltage： | 400VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Features
- All products have passed CCC, CE, and UL product certifications.
- A new member of the Line family, featuring the concept of system integration, a unified appearance design concept, and systematized installation and connection.
- Easy to install and wire, with screw and spring terminal wiring options available. All terminals and markings are located on the same front side of the product.
- The structure is designed to be compact and ingenious. Regardless of AC/DC coils, screw/spring terminals, and external dimensions being completely the same, after installing mechanical interlocks and surge suppressors, the product does not increase in width or volume.
- Designed for the needs of OEM customers, single packaging or multiple packagings (40 per box) can be provided.
Product Overview
- The AS and ASL series of general - purpose contactors have a compact structure, reliable operation, and easy installation. They are mainly used to control AC motors with a rated operating voltage of up to AC 690V. They are especially suitable for industries such as air conditioners, water pumps, elevators, machine tools, and food machinery. They can also be used in other occasions such as circuit switching and lighting control.
- The AS and ASL series contactors can form a direct motor starter with MS116 for the control and protection of motors, and have protection functions such as short - circuit, overload, and phase failure.
