Advanced Graphics Terminal

Advanced graphic terminals are used for industrial human-machine interaction. ICX provides high-resolution touch screen terminals, supports multi-language interface, data visualization and network communication functions, and is suitable for operation monitoring and parameter setting of industrial automation equipment.

Results: 19

Applied Filters:

Industrial Control

Industrial Control and Automation

Human Machine Interface

Advanced Graphics Terminal

Reset Apply

Product

Brand	Title	Function	Color	Resolution	Screen Size
Advantech	Advantech WOP-108K-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	800*600	8 inches
Advantech	Advantech WOP-112T-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	1024*768	12 inches
Advantech	Advantech WOP-112K-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	1024*768	12 inches
Advantech	Advantech WOP-110T-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	1024*600	10.1 inches
Advantech	Advantech WOP-107K-SAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	800*480	7 inches
Advantech	Advantech WOP-107E-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	16,777,215 colors	800*480	7 inches
Advantech	Advantech WOP-115T-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	1024*768	15 inches
Advantech	Advantech WOP-108T-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	800*600	8 inches
Advantech	Advantech WOP-107T-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	800*480	7 inches
Advantech	Advantech WOP-104K-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	480*272	4.3 inches
Advantech	Advantech WOP-104K-SAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	480*272	4.3 inches
Advantech	Advantech WOP-110K-SAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	1024*600	10.1 inches
Advantech	Advantech WOP-110E-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	16,777,215 colors	1024*600	10 inches
Advantech	Advantech WOP-104T-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	480*272	4.3 inches
Advantech	Advantech WOP-110K-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	1024*600	10.1 inches
Advantech	Advantech WOP-115K-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	1024*768	15 inches
Advantech	Advantech WOP-107K-NAE Advanced Graphic Terminal	Industrial-grade programmable human-machine interface	65,536 colors	800*480	7 inches
Schneider	Schneider HMIGXU3512 Advanced Graphic Terminal	LED touch screen	16-bit color	800*480	7 inches
Schneider	Schneider HMIGXU5512 Advanced Graphic Terminal	LED touch screen	16-bit color	800*480	10.1 inches
