Servo Motor

Servo motors are used for high-precision motion control. ICX provides AC servo motors, DC servo motors and other products that support high speed, high torque output and precise positioning. They are suitable for precision control scenarios such as semiconductor equipment and automated production lines.

Results: 448

Applied Filters:

Industrial Control

Industrial Control and Automation

Motion Control

Servo Motor

Reset Apply

Product

Brand	Title	Rated Current	Rated Power	Protection Level	Holding Brake	Rated Torque	Inertia Type	Rated Speed	Axis Type	Flange Size
Siemens	Siemens 1FL2204-4AF00-1HC0 Servo Motor	3A	1KW	IP54	none	3.26Nm	Medium inertia	3000rpm	Keyed shaft	81mm
Siemens	Siemens 1FL2203-4AF00-1HC0 Servo Motor	1.3A	0.4KW	IP54	none	1.27Nm	Medium inertia	3000rpm	Keyed shaft	60.2mm
Siemens	Siemens 1FL2102-2AG00-0MC0 Servo Motor	0.81A	0.05KW	IP54	none	0.16Nm	Low inertia	3000rpm	Optical axis end	40.6mm
Siemens	Siemens 1FL2104-2AG00-0SC0 Servo Motor	4.4A	0.75KW	IP54	none	2.4Nm	Low inertia	3000rpm	Optical axis end	81mm
Siemens	Siemens 1FL6024-2AF21-1AA1 Servo Motor	1.2A	0.1KW	IP65	none	0.32Nm	Low inertia	3000rpm	Keyed shaft	12010040mm
Siemens	Siemens 1FL2103-4AF10-0MC0 Servo Motor	1.3A	0.4KW	IP54	have	1.27Nm	Low inertia	3000rpm	Optical axis end	60.2mm
Siemens	Siemens 1FL2102-4AF11-0MC0 Servo Motor	0.81A	0.1KW	IP65	have	0.32Nm	Low inertia	3000rpm	Optical axis end	40.6mm
Siemens	Siemens 1FL2104-2AF10-0SC0 Servo Motor	2.1A	0.75KW	IP54	have	2.4Nm	Low inertia	3000rpm	Optical axis end	81mm
Siemens	Siemens 1FL2103-4AF11-0SC0 Servo Motor	1.3A	0.4KW	IP65	have	1.27Nm	Low inertia	3000rpm	Optical axis end	60.2mm
Siemens	Siemens 1FL2102-4AF10-0SC0 Servo Motor	0.81A	0.1KW	IP54	have	0.32Nm	Low inertia	3000rpm	Optical axis end	40.6mm
Siemens	Siemens 1FL2103-2AF10-0HC0 Servo Motor	1.3A	0.2KW	IP54	have	0.64Nm	Low inertia	3000rpm	Optical axis end	60.2mm
Siemens	Siemens 1FL2102-4AF11-0HC0 Servo Motor	0.81A	0.1KW	IP65	have	0.32Nm	Low inertia	3000rpm	Optical axis end	40.6mm
Siemens	Siemens 1FL2104-2AF01-0MC0 Servo Motor	2.1A	0.75KW	IP65	none	2.4Nm	Low inertia	3000rpm	Optical axis end	81mm
Siemens	Siemens 1FL2102-4AF01-0MC0 Servo Motor	0.81A	0.1KW	IP65	none	0.32Nm	Low inertia	3000rpm	Optical axis end	40.6mm
Siemens	Siemens 1FL2103-4AF00-0SC0 Servo Motor	1.3A	0.4KW	IP54	none	1.27Nm	Low inertia	3000rpm	Optical axis end	60.2mm
Siemens	Siemens 1FL2104-2AF01-0HC0 Servo Motor	2.1A	0.75KW	IP65	none	2.4Nm	Low inertia	3000rpm	Optical axis end	81mm
Siemens	Siemens 1FL2104-2AF00-0HC0 Servo Motor	2.1A	0.75KW	IP54	none	2.4Nm	Low inertia	3000rpm	Optical axis end	81mm
Siemens	Siemens 1FL2103-2AF01-0HC0 Servo Motor	1.3A	0.2KW	IP65	none	0.64Nm	Low inertia	3000rpm	Optical axis end	60.2mm
Siemens	Siemens 1FL2102-4AF01-0HC0 Servo Motor	0.81A	0.1KW	IP65	none	0.32Nm	Low inertia	3000rpm	Optical axis end	40.6mm
Siemens	Siemens 1FL2104-2AF10-1MC0 Servo Motor	2.1A	0.75KW	IP54	have	2.4Nm	Low inertia	3000rpm	Keyed shaft	81mm
