Air Ventilator

The ICX platform offers a variety of air ventilators suitable for industrial protection, medical, and air safety scenarios. We partner with globally renowned brands to ensure their products meet safety standards and provide users with comfortable and stable respiratory protection.

Results: 40

Applied Filters:

HVAC

Ventilation Equipment

Mechanical Ventilation

Air Ventilator

Reset Apply

Product

Brand	Title	Connection Size	Power	Rated Voltage	Air Volume	Static Pressure	Noise	Frequency
ICX	K-B2K B Series	Air Inlet：443x280mm Air Outlet：300x156mm	180 W	380 V	2600 m³/h	350 Pa	45 dB
ICX	K-B3K B Series	Air Inlet：503x302mm Air Outlet：343x156mm	320 W	380 V	3200 m³/h	400 Pa	50 dB
ICX	K-B4K B Series	Air Inlet：543x322mm Air Outlet：343x171mm	550 W	380 V	4200 m³/h	450 Pa	54 dB
ICX	K-B5K B Series	Air Inlet：563x377mm Air Outlet：343x256mm	800 W	380 V	5200 m³/h	500 Pa	60 dB
ICX	K-B6K B Series	Air Inlet：583x412mm Air Outlet：368x290mm	1100 W	380 V	6200 m³/h	600 Pa	62 dB
ICX	K-B7K B Series	Air Inlet：603x437mm Air Outlet：394x290mm	1500 W	380 V	7200 m³/h	650 Pa	65 dB
ICX	K-B8K B Series	Air Inlet：653x452mm Air Outlet：394x300mm	1500 W	380 V	8000 m³/h	700 Pa	66 dB
ICX	K-B9K B Series	Air Inlet：653x487mm Air Outlet：394x300mm	1800 W	380 V	9000 m³/h	750 Pa	68 dB
ICX	K-B10K B Series	Air Inlet：703x487mm Air Outlet：394x300mm	2200 W	380 V	10000 m³/h	800 Pa	70 dB
ICX	K-B13K B Series	Air Inlet：813x592mm Air Outlet：453x330mm	3000 W	380 V	13000 m³/h	850 Pa	73 dB
ICX	K-B16K B Series	Air Inlet：813x622mm Air Outlet：453x340mm	4000 W	380 V	16000 m³/h	900 Pa	74 dB
ICX	K-DPT35-A DPT Series	Air Inlet：580x145mm Air Outlet：580x145mm	550 W	220 V	2500 m³/h	210 Pa	40 dB	50 Hz
ICX	K-DPT40-A DPT Series	Air Inlet：660x165mm Air Outlet：660x165mm	730 W	220 V	3500 m³/h	260 Pa	42 dB	50 Hz
ICX	K-DPT50-A DPT Series	Air Inlet：835x245mm Air Outlet：835x245mm	800 W	380 V	5000 m³/h	270 Pa	48 dB	50 Hz
ICX	K-DPT60-A DPT Series	Air Inlet：915x315mm Air Outlet：915x315mm	1600 W	380 V	8000 m³/h	400 Pa	55 dB	50 Hz
ICX	K-DPT70-A DPT Series	Air Inlet：1000x360mm Air Outlet：1000x360mm	3000 W	380 V	13000 m³/h	550 Pa	65 dB	50 Hz
ICX	K-DPT35-S DPT Series	Air Inlet：240x145mm Air Outlet：240x145mm	550 W	220 V	1250m³/h（Exhaust）1250m³/h（Supply）	210 Pa	40 dB	50 Hz
ICX	K-DPT40-S DPT Series	Air Inlet：280x165mm Air Outlet：280x165mm	730 W	220 V	1750m³/h（Exhaust）1750m³/h（Supply）	260 Pa	42 dB	50 Hz
ICX	K-DPT50-S DPT Series	Air Inlet：345x245mm Air Outlet：345x245mm	800 W	380 V	2500m³/h（Exhaust）2500m³/h（Supply）	270 Pa	48 dB	50 Hz
ICX	K-DPT60-S DPT Series	Air Inlet：390x315mm Air Outlet：390x315mm	1600 W	380 V	4000m³/h（Exhaust）4000m³/h（Supply）	400 Pa	55 dB	50 Hz
