Delixi CJ20-100A 380V
Brand:
Series:
CJ20
Main Contacts:
3NO
Control Circuit:
AC 50Hz
Control Coil Voltage:
380VAC
Auxiliary Contacts:
2NO+2NC
Rated Current:
100A
Poles:
3P
Rated Voltage:
380VAC
Model:
CJ20-100A 380V
Order Number:
CJ2010022Q
Description:
Delixi AC contactor CJ20-100A 380V, auxiliary contacts 2NO+2NC, poles 3P, 100A, control circuit AC 50Hz, main contacts 3NO, 380VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Delixi | |
| Series： | CJ20 | |
| Main Contacts： | 3NO | |
| Control Circuit： | AC 50Hz | |
| Control Coil Voltage： | 380VAC | |
| Auxiliary Contacts： | 2NO+2NC | |
| Rated Current： | 100A | |
| Poles： | 3P | |
| Rated Voltage： | 380VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Description
- Suitable for power systems with AC 50Hz, a maximum rated operating voltage of up to 1000V, and in the AC - 3 usage category, when the rated operating voltage is 380V, the rated operating current is 630A. It is used for remotely connecting and disconnecting circuits and can be combined with appropriate thermal overload relays such as JR20 or electronic protection devices to form electromagnetic starters to protect circuits that may be overloaded during operation.
Product Features
- In addition to screw installation, the product can also be installed on 35mm (75mm) standard guide rails. The contactor has a double - break direct - acting structure with a vertical three - dimensional layout. For currents below 40A, an E - type iron core is used; for 40A and above, a U - type iron core is used. The air gap is placed in the center of the bottom of the static iron core to ensure the air gap remains unchanged. For currents above 63A, a ship - shaped moving contact bridge is used, and an iron - based arc - guiding horn is installed.
