Huanyu CJX1-9Z/24V
Brand:
Series:
CJX1
Main Contacts:
3NO
Control Circuit:
DC 50/60Hz
Control Coil Voltage:
24VDC
Auxiliary Contacts:
2NO+2NC
Rated Current:
9A
Poles:
3P
Rated Voltage:
380VAC
Model:
CJX1-9Z/24V
Order Number:
1010700121
Description:
Huanyu AC contactor CJX1-9Z/24V, auxiliary contacts 2NO+2NC, poles 3P, control circuit DC 50/60Hz, main contacts 3NO, 380VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Huyu | |
| Series： | CJX1 | |
| Main Contacts： | 3NO | |
| Control Circuit： | DC 50/60Hz | |
| Control Coil Voltage： | 24VDC | |
| Auxiliary Contacts： | 2NO+2NC | |
| Rated Current： | 9A | |
| Poles： | 3P | |
| Rated Voltage： | 380VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Information
- The CJX1 series AC contactors are suitable for power circuits with AC 50Hz or 60Hz, a voltage of up to 660V, and a current of up to 475A. They are used for remote and frequent starting, controlling electric motors, as well as connecting and disconnecting circuits. After being combined with a mechanical interlocking mechanism, they form the reversible CJX1 series contactors, which can control the starting, stopping, and reversing of electric motors.
- This product complies with standards such as GB14048.4 and IEC60947 - 4 - 1.
- The CJX1 - Z DC - operated contactors are suitable for power lines with a rated operating voltage of up to 660V and a rated operating current of up to 22A. They are mainly used for remotely connecting and disconnecting circuits in electrical equipment such as those in the metallurgical, steel rolling enterprises, and cranes.
- This product complies with the GB14048.4 standard.
Normal Operating Conditions
- Ambient air temperature: - 5°C - + 40°C, with the 24 - hour average value not exceeding + 35°C;
- Altitude: not exceeding 2000m;
- Atmospheric conditions: The relative humidity of the air at the installation site does not exceed 50% at + 40°C. Higher relative humidity is allowed at lower temperatures, for example, reaching 90% at 20°C. Special measures should be taken for condensation occasionally generated due to temperature changes;
- Pollution level: 3;
- Installation category: III;
- Installation conditions: The inclination of the installation surface from the vertical is not more than ± 5°;
- Shock and vibration: Installed in a place without significant shaking, impact, and vibration.
- Transportation and storage: The contactors should not be subject to severe collisions and vibrations during transportation. They should not be exposed to rain and snow during transportation and storage. The contactors are suitable for transportation and storage at temperatures between - 25°C - + 55°C, and can be transported and stored at temperatures up to + 70°C for a short time (within 24 hours).
