Huanyu CJX2-F150 Contactor
Brand:
Series:
CJX2-F
Main Contacts:
-
Control Circuit:
AC 50/60Hz
Control Coil Voltage:
-
Auxiliary Contacts:
-
Rated Current:
150A
Poles:
-
Rated Voltage:
380VAC
Model:
CJX2-F150 Contact
Order Number:
1010800755
Description:
Huanyu AC contactor CJX2-F150 contact, number of poles -, control circuit AC 50/60Hz, main contact -, 380VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Huyu | |
| Series： | CJX2-F | |
| Main Contacts： | - | |
| Control Circuit： | AC 50/60Hz | |
| Control Coil Voltage： | - | |
| Auxiliary Contacts： | - | |
| Rated Current： | 150A | |
| Poles： | - | |
| Rated Voltage： | 380VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Information
- The CJX2 - F series AC contactors (hereinafter referred to as contactors) are mainly used in circuits with AC 50Hz (or 60Hz), a rated operating voltage of up to 1000V, and a rated operating current of up to 630A. They are used for remote connection and disconnection as well as frequent starting to control AC motors. The contactors can also be conveniently equipped with auxiliary contact blocks or air delay heads and other accessories, and can form electromagnetic starters with appropriate thermal overload relays.
- This product complies with standards such as GB14048.4 and IEC60947 - 4 - 1.
Normal Operating Conditions
- Ambient air temperature: - 5°C ~ + 40°C, with the 24 - hour average value not exceeding + 35°C.
- Altitude: not exceeding 2000m.
- Atmospheric conditions: The relative humidity of the air at the installation site does not exceed 50% at + 40°C. Higher relative humidity is allowed at lower temperatures, for example, reaching 90% at 20°C. Special measures should be taken for condensation occasionally generated due to temperature changes.
- Pollution level: 3.
- Installation category: III.
- Installation conditions: The inclination of the installation surface from the vertical is not more than ± 5°. When the control voltage at the coil end is not less than 85% Us, it is not more than ± 30°.
- Shock and vibration: The contactors should be installed and used in a place without significant shaking, impact, and vibration.
- Transportation and storage: The contactors should not be subject to severe collisions and vibrations during transportation. They should not be exposed to rain and snow during transportation and storage. The contactors are suitable for transportation and storage at temperatures between - 25°C ~ + 55°C, and can be transported and stored at temperatures up to + 70°C for a short time (within 24 hours).
