Schneider LC1-D205F7C
Brand:
Series:
LC1D (domestic)
Main Contacts:
3NO
Control Circuit:
AC 50/60Hz
Control Coil Voltage:
110VAC
Auxiliary Contacts:
-
Rated Current:
205A
Poles:
3P
Rated Voltage:
440VAC
Model:
LC1-D205F7C
Order Number:
LC1D205F7C
Description:
Schneider AC contactor LC1-D205F7C, pole number 3P, 205A, control circuit AC 50/60Hz, main contact 3NO, 440VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Schneider | |
| Series： | LC1D (domestic) | |
| Main Contacts： | 3NO | |
| Control Circuit： | AC 50/60Hz | |
| Control Coil Voltage： | 110VAC | |
| Auxiliary Contacts： | - | |
| Rated Current： | 205A | |
| Poles： | 3P | |
| Rated Voltage： | 440VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Functions
- Current range 09 - 620A;
- AC, DC control coils optional (DC coils up to 38A);
- Applicable to different types of starters: standard motor - starting contactors, reversible contactors, star - delta starters, autotransformer starters, etc.;
- Connection methods optional: screw connection (09 - 620A), ring terminal connection (09 - 38A), EverLink terminal connection (40 - 65A), facilitating customer installation;
- Product certifications: CCC, CE, CCS;
Advantages
- Compact Installation
- Contactors up to 38A and protection components are only 45mm in width.
- Surge suppressors can be installed without tools, directly plugged into the contactor, without occupying more space.
- Reversible contactors are only 90mm in width. Mechanical interlocking does not occupy extra space, and installation takes almost no time.
- Starter components provide pre - wired modules for quick and convenient assembly.
- High Integration
- Contactors up to 100A integrate 1 normally open / 1 normally closed auxiliary contact.
- DC coils have built - in bidirectional freewheeling diodes.
- Reversible contactor groups have built - in bidirectional freewheeling diodes.
- Safe and Reliable
- The main circuit and control circuit of control and protection components are clearly distinguished.
- Mirror contact design meeting safety standards ensures reliable operation once.
- Protective cover prevents accidental connection of contactors.
- Superior Quality
- DC coils have a wide - range control voltage (0.7 - 1.25UC).
- High vibration resistance.
- Lower noise.
- Improved terminal strength.
- TeSysD 40 - 65A Everlink:
- Long - lasting torque for reliable installation.
- Small and compact, saving space.
- Easy and time - saving installation.
- Easy to maintain, reducing costs.
- Two - dimensional code identification technology.
- Warranty period: 18 months.
Applications
- TeSys D contactors are designed for various control systems;
- Can be used as motor starters in various application situations.
