Siemens 3RT1055-6AB36
Brand:
Series:
3RT1
Main Contacts:
3NO
Control Circuit:
AC/DC
Control Coil Voltage:
23-26VAC/DC
Auxiliary Contacts:
2NO+2NC
Rated Current:
150A
Poles:
3P
Rated Voltage:
400VAC
Model:
3RT1055-6AB36
Order Number:
3RT10556AB36
Description:
Siemens AC contactor 3RT1055-6AB36, auxiliary contacts 2NO+2NC, poles 3P, control circuit AC/DC, main contacts 3NO, 400VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 3RT1 | |
| Main Contacts： | 3NO | |
| Control Circuit： | AC/DC | |
| Control Coil Voltage： | 23-26VAC/DC | |
| Auxiliary Contacts： | 2NO+2NC | |
| Rated Current： | 150A | |
| Poles： | 3P | |
| Rated Voltage： | 400VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
3RT10 AC/DC Contactor, 3 - pole
- AC/DC operation (40Hz...60Hz, DC)
- Replaceable coil
- Integrated coil circuit (varistor)
- Auxiliary wires and control wires: screw terminal connection or cage clamp connection
- Main conductor: terminal block connection; 3rt10 54 (55KW) is in the form of terminal box connection type 1
- 3RT1 contactors are suitable for any climatic environmental conditions. The safe touch protection function meets the requirements of Part 100 of DIN VDE 0106.
- 3RT1 contactors can use screw terminal connection or cage clamp terminal connection.
- The basic unit of S00 - sized contactors has auxiliary contacts containing a set of auxiliary contacts. The basic units from S0 to S3 sizes are composed of main circuit contacts.
- All basic units can be expanded with auxiliary contact modules. The contact group with 2 normally open contacts and 2 normally closed contacts (terminal design complies with EN 50012) can be used for S0 and larger sizes; the auxiliary contact modules can be disassembled.
- In addition, for S00 and S0 sizes, a set of auxiliary contact modules (2 normally open + 2 normally closed, complying with EN50 012 standard) can be fixedly installed on the contact group. These types comply with Swiss special regulations (SUVA) and are distinguished by external red nameplates.
- S3 - sized contactors have a movable terminal box for connecting the main circuit busbar. Therefore, ring cable lugs or terminal posts can be connected.
- Used as contactors for motors complying with IEC 6047/DIN, EN 60947 (VDE 0660). With screw terminals, and using connection components, they can be quickly, simply, and clearly connected with circuit breakers and/or overload relays to form a circuit.
- Auxiliary contacts can be installed on the contactor body.
