Siemens 3RT7036-1AN20 AC220V 50/60HZ 50A
Brand:
Series:
3RT7
Main Contacts:
3NO
Control Circuit:
AC 50/60Hz
Control Coil Voltage:
220VAC
Auxiliary Contacts:
-
Rated Current:
50A
Poles:
3P
Rated Voltage:
400VAC
Model:
3RT7036-1AN20 AC220V 50/60HZ 50A
Order Number:
3RT70361AN20
Description:
Siemens AC contactor 3RT7036-1AN20 AC220V 50/60HZ 50A, pole number 3P, 50A, control circuit AC 50/60Hz, main contact 3NO, 400VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 3RT7 | |
| Main Contacts： | 3NO | |
| Control Circuit： | AC 50/60Hz | |
| Control Coil Voltage： | 220VAC | |
| Auxiliary Contacts： | - | |
| Rated Current： | 50A | |
| Poles： | 3P | |
| Rated Voltage： | 400VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
S00 to S3 frame sizes, up to 45kW
Standards
- IEC 60947-1
- IEC 60947-4-1
- IEC 60947-5-1 (auxiliary contacts)
- 3RT7 contactors have passed climatic testing and are suitable for any climatic conditions.
- When the environment of equipment application is different from the standard industrial environment (specified in EN 60721-3-3), it is necessary to consider the impact of the environment on product reliability and service life, and take corresponding protective measures. If necessary, contact Siemens Technical Support.
Adding Auxiliary Contacts
- S00 frame size contactors are integrated with 1 auxiliary contact (1NO or 1NC) in themselves.
- S0 frame size contactors are integrated with 2 auxiliary contacts (1NO + 1NC) in themselves or without auxiliary contacts.
- S2 and S3 frame size contactors have no auxiliary contacts integrated in themselves.
- All frame size contactors can be further equipped with detachable auxiliary contact blocks.
- A maximum of 5 auxiliary contacts can be achieved for S00 frame size.
- A maximum of 4 auxiliary contacts can be achieved for S0/S2 frame sizes.
- A maximum of 8 auxiliary contacts can be achieved for S3 frame size.
- For all frame sizes, the number of normally closed contacts shall not exceed 4.
Motor Reference Power
- The motor power mentioned in the sample is the reference motor shaft output power (according to the nameplate).
Rated Control Voltage
- All contactors have models for AC operation.
Surge Suppression
- 3RT7 contactors can provide RC (resistance-capacitance absorption) surge suppressors for suppressing coil surges.
