Siemens 3TG1001-0AL2
Brand:
Series:
3TG10
Main Contacts:
3NO+1NC
Control Circuit:
AC 45…450Hz
Control Coil Voltage:
230VAC
Auxiliary Contacts:
1NO
Rated Current:
8.4A
Poles:
3P
Rated Voltage:
400VAC
Model:
3TG1001-0AL2
Order Number:
3TG10010AL2
Description:
Siemens AC contactor 3TG1001-0AL2, auxiliary contact 1NO, pole number 3P, control circuit AC 45...450Hz, main contact 3NO+1NC, 400VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 3TG10 | |
| Main Contacts： | 3NO+1NC | |
| Control Circuit： | AC 45…450Hz | |
| Control Coil Voltage： | 230VAC | |
| Auxiliary Contacts： | 1NO | |
| Rated Current： | 8.4A | |
| Poles： | 3P | |
| Rated Voltage： | 400VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
High Performance, Small Size
- 3TG10 power relays are ideal solutions for all applications that require small - sized low - noise relays or low - cost contactors. Power relays are suitable for basic control, especially for use in large - scale series equipment and control devices. They are suitable for applications that only need one auxiliary contact and do not need overload relays, which put forward higher requirements for breaking capacity, breaking voltage, and service life.
Applications
- Household appliances and equipment
- Lifting systems: small elevators, lifting platforms.
- Construction facilities, no - noise equipment in building systems, such as hospitals.
Configuration Information
- The three main current paths carry a load of 20 A. When the current on the fourth current path I > 10 A, the following situation occurs: the allowable ambient temperature is 40°C
Advantages
- No noise in any installation position
- Safe isolation
- Screw or plug - in connection
- Integrated auxiliary contacts
- AC - 3 power supply: 4 kW / 400 V
- Operating current Ie / AC - 1:20 A / 400 V
- Inrush current per phase: 90 A
- Integrated overvoltage damping
- Narrow width, only 36 mm
