Siemens 3TS3411-0XF0 110V 32A
Brand:
Series:
3TS
Main Contacts:
3NO
Control Circuit:
AC 50Hz
Control Coil Voltage:
110VAC
Auxiliary Contacts:
1NO+1NC
Rated Current:
32A
Poles:
3P
Rated Voltage:
380VAC
Model:
3TS3411-0XF0 110V 32A
Order Number:
3TS34110XF0
Description:
Siemens AC contactor 3TS3411-0XF0 110V auxiliary contact 1NO+1NC, pole number 3P, control circuit AC 50Hz, main contact 3NO, 380VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 3TS | |
| Main Contacts： | 3NO | |
| Control Circuit： | AC 50Hz | |
| Control Coil Voltage： | 110VAC | |
| Auxiliary Contacts： | 1NO+1NC | |
| Rated Current： | 32A | |
| Poles： | 3P | |
| Rated Voltage： | 380VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Description
- The 3TS series AC contactors are used for AC 50Hz or 60Hz, with a rated insulation voltage of 690 - 1000V. Under the AC - 3 usage category, when the rated operating voltage is 380V, the rated operating current ranges from 6A to 400A. They are mainly used for remote connection and disconnection of circuits, and are suitable for controlling the start, stop, and reversal of AC motors. They comply with standards such as IEC60947 and GB14048.
Operating Conditions
- Altitude not exceeding 2000 meters.
- Ambient temperature: - 25 - + 55°C.
- Relative air humidity: not exceeding 50% at + 40°C, and not exceeding 90% at + 25°C.
- Atmospheric conditions: no medium that may cause explosion hazards, and no gases and conductive dust that corrode metals and damage insulation.
- In a place without significant shaking and impact vibration.
- In a place without rain and snow erosion.
Structural Features
- Good safety performance, with conductive parts not exposed.
- Small size, light weight, and the arc - extinguishing cover material uses unsaturated resin, which has good arc resistance and will not crack.
- The arc - extinguishing chamber is of a sealed type, with a small arc - flying distance, which can reduce the size of the electrical cabinet.
- The main contact system has a unique structure, with little contact wear and increased electrical service life.
- The electromagnet works reliably, with low loss, low noise, and very high mechanical strength, as well as high operating frequency and control capacity.
- The 3TS29 - 36 series can be additionally equipped with auxiliary contact bases.
