TENGEN CJX1-45/22 380V
Brand:
Series:
CJX1
Main Contacts:
3NO
Control Circuit:
AC 50/60Hz
Control Coil Voltage:
380VAC
Auxiliary Contacts:
2NO+2NC
Rated Current:
45A
Poles:
3P
Rated Voltage:
380VAC
Model:
CJX1-45/22 380V
Order Number:
02010060063
Description:
AC contactor CJX1-45/22 380V, auxiliary contacts 2NO+2NC, poles 3P, 45A, control circuit AC 50/60Hz, main contacts 3NO, 380VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | TENGEN | |
| Series： | CJX1 | |
| Main Contacts： | 3NO | |
| Control Circuit： | AC 50/60Hz | |
| Control Coil Voltage： | 380VAC | |
| Auxiliary Contacts： | 2NO+2NC | |
| Rated Current： | 45A | |
| Poles： | 3P | |
| Rated Voltage： | 380VAC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
- The CJX1 series AC contactors are mainly used in power lines with AC 50Hz or 60Hz, a rated insulation voltage of 660V, and in the AC - 3 usage category, when the rated operating voltage is 380V, the rated operating current ranges from 9A to 475A. They are used for remotely connecting and disconnecting circuits, and are suitable for controlling the starting, stopping, and reversing of AC motors.
- The product complies with GB14048.4, IEC60947 - 4 - 1, and GB21518.
Normal Operating and Installation Conditions
- Ambient temperature: upper limit + 40°C, with an average not exceeding + 35°C within 24h; lower limit - 5°C;
- Altitude: not exceeding 2000m;
- Atmospheric conditions: not exceeding 50% at the maximum temperature of + 40°C, and higher relative humidity is allowed at lower temperatures. When the monthly average minimum temperature in the wettest month does not exceed + 25°C, the monthly average maximum relative humidity in that month does not exceed 90%. Corresponding measures must be taken for condensation on the product due to temperature changes.
- Installation category: III;
- Pollution level: 3;
- Shock and vibration: installed in a place without significant shaking, impact, and vibration.
