ABB MP1-31Y Flat button head
Brand:
Series:
M Series
Light Source:
-
Installation Diameter:
22mm
Color:
yellow
Material:
-
Function:
Reset type
Auxiliary Contacts:
-
Product Type:
Flat button head
Rated Voltage:
-
Model:
MP1-31Y
Order Number:
10093066
Description:
ABB push button accessories MP1-31Y, installation diameter 22mm, yellow, flat head button head, reset type
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | ABB | |
| Series： | M Series | |
| Light Source： | - | |
| Installation Diameter： | 22mm | |
| Color： | yellow | |
| Material： | - | |
| Function： | Reset type | |
| Auxiliary Contacts： | - | |
| Product Type： | Flat button head | |
| Rated Voltage： | - |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
- ABB provides a complete series of 22mm button and indicator devices, including indicator lights, buttons, emergency stop buttons, selector switches, toggle switches, joysticks, buzzers, potentiometers, etc.; and also provides button boxes and a full range of accessories at the same time.
- The main advantages of ABB's button and indicator devices are high protection levels and convenient and fast installation, which can save costs for customers. This product is suitable for various industrial environments, including outdoor use and some other applications, such as transport trucks, public buses, locomotives and vehicles, and public buildings.
Compact Product Series
- Compact products include illuminated/non - illuminated buttons, non - illuminated selector switches, and emergency stop buttons, etc.
- Single integrated unit, easy to select and use (one function corresponds to one order number)
- The front of the product has a protection level of IP67, and the rear has a protection level of IP20
- High - quality materials are selected, and all materials comply with UL certification
- Can have up to two auxiliary contacts at most (optional contact combinations: 1NO, 1NC, 2NO, 2NC or 1NO + 1NC)
- Contacts are color - coded for easy wiring and enhanced safety (NO is green, NC is red)
- The contacts have a self - cleaning function. The contacts can still maintain good conduction after long - term use and also have reliable performance at low currents.
Modular Product Series
- Modular products include illuminated/non - illuminated buttons, selector switches, emergency stop buttons, double - head buttons, toggle switches, and other series of products
- Customers can combine different component part numbers according to their needs to meet the required functions
- Suitable for outdoor and indoor use, with a protection level of up to IP66
- A maximum of 5 contacts can be configured in a single layer, and a maximum of 6 contacts can be configured in a double layer
- The contacts have a self - cleaning function, which can enhance the reliability of conduction; the contact rods have color codes for easy identification.
Illuminated Buttons
- Can provide compact and modular types. Compact products save installation space and can save costs for customers; modular products provide different function options to meet different needs of customers
- Product types: Self - locking type, reset type
- Colors:
- Compact type: Red, yellow, green
- Modular type: Red, green, yellow, blue, white, black, transparent
- Operating temperature: - 25°C to + 70°C
- Mechanical life: 500,000 operations
- Protection levels:
- IP67 (compact type)
- IP66 (modular type)
Emergency Stop Buttons
- Can provide compact and modular products
- Compact type: Single integrated unit, easy to select and use, can save costs and installation space for customers
- Modular type: Can provide different function options to meet different needs of customers
- Indication methods: Illuminated type/non - illuminated type
- Operation methods: Twist release/pull release/key release type
- Operating head diameters: Ø30, Ø40 and Ø60MM
- High protection levels:
- Compact products—front IP67, rear IP20
- Modular products—front IP66, rear IP20
Standard Testing
- ABB emergency stop buttons are designed according to the standard of IEC 60947 - 5 - 5. The electrical function is mechanically locked before activation to prevent misoperation, and has passed strict product testing to meet various use conditions, ensuring reliable quality and personal safety.
Performance Testing
- 1. Operation Test
- 6050 operations
- Long - term test of the locking part
- 2. Strength Test
- M = 0.1×D = 2.2 Nm
- F = 5×D = 113N
- 3. Humidity and Dryness Test
- Verify function after 96 - hour test
-
- 70°C dry air
- Hot and humid air (+ 25°C/+ 55°C, 97%/93% RH)
-
- 40°C
-
- 35°C 5% NaCl solution
- 4. Impact Test
- According to standard: IEC 60068 - 2 - 27
- Test parameters: Impact force: 15g (equivalent to 150m/s²), duration: 11ms
- During the test, closed contacts cannot open, opened contacts cannot close, and the locking mechanism cannot lock/unlock
- 5. Vibration Test
- Frequency: 10 - 100Hz, time: 2 hours, acceleration: 50m/s², amplitude: 0.35mm
- 6. Locking and Unlocking Test
- The actuator of the emergency stop switch should move slowly until the locking point, and the normally closed contact should open here.
- Tested by a pulse voltage at 2500V.
- 7. Locking and Unlocking Test
- According to IEC 60947 - 5 - 5/7.7.3
- Simulate the action of a normal operator
- The emergency stop button is installed in front of a 1.6kg hammer
- After being impacted, the locking mechanism should be locked. h = 75mm
- 8. Locking and Unlocking Test
- Reset pulling force should be less than: 50N
- Torque should be less than 1Nm
- 9. Impact Test
- Use a 1.6kg hammer to strike 3 times, h = 310mm
- After each impact, the emergency stop button should be triggered
- After three impacts, the emergency stop button should not be damaged
- 10. Function Test
- Types of use: AC - 15 and/or DG - 13 or DC - 14
- NC contact directly opens
Features
- L - MARK Custom Marking Patterns, Easy and Convenient
- ABB has newly developed a new system, making it easy for customers to customize marking patterns on button and indicator devices. In addition to engraving characters on the nameplate, ABB can also provide products with laser - printed custom patterns on the button and indicator devices. On the L - MARK website, customers will receive an order code for products with custom marking patterns. This code can be saved, making it easier to re - order and ensuring that customers get perfect customized products.
- Contact Self - Cleaning Function
- Whether for compact or modular products, the contact modules have a wiping action, enabling the contact self - cleaning function. During operation, the moving contact rolls and then slides to the side after contacting the static contact. Due to this feature, the contact self - cleaning function can be ensured even in low - current applications.
- Fast and Convenient Installation
- The installation of all ABB button and indicator devices is very convenient and flexible. Elastic installation can ensure the accurate position of the operating head and the nameplate. The operating head of ABB can be used in both countersunk holes and round holes. The product adopts a modular card - loading design and is one of the fastest - assembling products on the market.
