Schneider ZBY6H102 30*40mm embedded scale plate base

Name: Schneider ZBY6H102 30*40mm embedded scale plate base
SKU: ZBY6H102

Brand:

Schneider

Series:

XB4

Light Source:

Installation Diameter:

22mm

Color:

Material:

Function:

Auxiliary Contacts:

Product Type:

30*40mm embedded scale plate base

Rated Voltage:

Model:

ZBY6H102

Order Number:

ZBY6H102

Description:

Schneider button accessory ZBY6H102, installation diameter 22mm, 30*40mm embedded scale plate base

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	XB4
Light Source：	-
Installation Diameter：	22mm
Color：	-
Material：	-
Function：	-
Auxiliary Contacts：	-
Product Type：	30*40mm embedded scale plate base
Rated Voltage：	-

Products with the same attribute : 0

Show details

Series Overview

Spring - return buttons, illuminated buttons, selector switches, mushroom - head emergency stop buttons, etc.
Equipped with LED indicator lights, incandescent lamps, and neon lamps.
Comply with IEC, UL, CSA certification standards.
CE marking.
IP66, NEMA4 protection levels.
"Protected LED" light - emitting units.
Low - current electrical contacts.
Fastening screw terminal connection method and printed circuit board pin connection method available for selection.
Complete product series.
Modular product design facilitates customized installation and use by customers.

Advantages

A series of products designed for the application requirements of various industrial sites, featuring easy installation, a wide range of applications, and being sturdy and durable.
The innovative locking mechanical system of the operating head and the main body, as well as the single - screw tightening design, greatly facilitate customers' installation and use and improve efficiency.

Application Scope

Industries: machinery manufacturing (automobile, textile machinery, woodworking machinery), control system panel cabinet manufacturing, etc.
Downstream applications: power distribution panel factories, public utilities, buildings, airports, etc.
