Delixi LAY7-11M Green Button
Brand:
Series:
LAY7
Lamp Holder Rated Voltage:
-
Base Material:
plastic
Light Source:
-
Installation Diameter:
22mm
Color:
green
Function:
Reset type
Auxiliary Contacts:
1NO+1NC
Product Type:
Mushroom head button
Model:
LAY7-11M Green
Order Number:
LAY711M32
Description:
installation diameter 22mm, green, reset type, plastic, mushroom head push button, auxiliary contact 1NO + 1NC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Delixi | |
| Series： | LAY7 | |
| Lamp Holder Rated Voltage： | - | |
| Base Material： | plastic | |
| Light Source： | - | |
| Installation Diameter： | 22mm | |
| Color： | green | |
| Function： | Reset type | |
| Auxiliary Contacts： | 1NO+1NC | |
| Product Type： | Mushroom head button |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
The LAY7 series button switches are used in industrial control circuits with an AC frequency of 50Hz, a rated working voltage of AC 380V or below, or DC 220V or below. They are used for remote control in circuits of magnetic starters, contactors, relays, and other electrical appliances. Button switches with indicators are also suitable for occasions requiring light signal indication.
Compliance with Standards
- GB14048.5
Ambient Temperature
- Not lower than -5°C, not higher than +40°C, and the 24 - hour average value does not exceed +35°C.
Altitude
- Not exceeding 2000m.
Atmospheric Conditions
- The relative humidity of the surrounding air is 45% - 85% (no condensation).
- No significant vibration or impact - vibration places.
- In a medium without explosion danger, and the medium does not contain gases and dust sufficient to corrode metals and damage insulation. In places not invaded by rain and snow.
Pollution Degree
- Grade 3.
Installation Category
- Category II.
Structural Features
- The contact element has a double - break point type with two wiring terminals.
- The normally open and normally closed contacts are structurally separated and electrically insulated, and can work with different rights.
- Contact groups can be arbitrarily combined for easy replacement.
- Equipped with an anti - rotation positioning ring, with accurate and reliable positioning.
- The wiring terminals all use M3.5 combination screws.
