TENGEN TGLA39-20BND DC24V Green Button
Brand:
Series:
TGLA39
Lamp Holder Rated Voltage:
24VDC
Base Material:
plastic
Light Source:
With light bulb
Installation Diameter:
22.3mm
Color:
green
Function:
Reset type
Auxiliary Contacts:
2NO
Product Type:
LED flat push button
Model:
TGLA39-20BND DC24V Green
Order Number:
08010170112
Description:
installation diameter 22.3mm, light source with bulb, green, reset type, plastic, lamp holder rated voltage 24VDC, LED type flat head button, auxiliary contact 2NO
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | TENGEN | |
| Series： | TGLA39 | |
| Lamp Holder Rated Voltage： | 24VDC | |
| Base Material： | plastic | |
| Light Source： | With light bulb | |
| Installation Diameter： | 22.3mm | |
| Color： | green | |
| Function： | Reset type | |
| Auxiliary Contacts： | 2NO | |
| Product Type： | LED flat push button |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
This series of products is suitable for AC 50HZ (or 60Hz) with a voltage below 660V and a DC voltage below 440V in electromagnetic starters, contactors, relays and other electrical circuits for remote control purposes. Button switches with indicators are also suitable for occasions requiring light signal indication.
Compliance with Standards
- GB14048.5
Ambient Temperature
- Not exceeding +40°C, and the average temperature within 24 hours does not exceed +35°C. The lower limit of the surrounding air temperature is -5°C.
Altitude
- Not exceeding 2000m.
Atmospheric Conditions
- When the maximum temperature is +40°C, the relative humidity of the air does not exceed 50%; at lower temperatures, a higher relative humidity is allowed, for example, reaching 90% at 20°C; special measures should be taken for condensation occasionally generated due to temperature changes.
Pollution Degree
- Grade 3.
Installation Category
- Category II.
Structure and Features
- The contact system of this series of button switches adopts a lever - type over - center toggle mechanism. During operation, even if the button stroke is insufficient, as long as it exceeds the over - center flip position, it can act quickly, making reliable contact or disconnection. Through the action of the tension spring, the necessary contact pressure is ensured, and it has a self - cleaning function, making the contact reliable and having good arc - extinguishing performance. When disconnecting, due to the vibration of the metal sheet, a clear click sound is emitted, giving the user a signal to know whether the command is executed.
- The combined card - mounting method allows for flexible, convenient and reliable assembly and disassembly. It can be equipped with two - section switch elements. The contacts have 1 - 4 pairs and can be combined into 1 - 14 specifications.
- Normally open and normally closed are electrically insulated and can work with different rights.
- There is a moisture - proof baffle at the wiring place, and combined screw wiring. The vertical washer prevents the screw from being pulled out and pressed down, making wiring convenient.
- The installation method adopts a screw - type fixed base, which is not only convenient but also safe and reliable.
