Tayee LA42P-10/G Button
Brand:
Series:
LA42
Base Material:
plastic
Light Source:
-
Installation Diameter:
22mm
Color:
green
Function:
Reset type
Auxiliary Contacts:
1NO
Product Type:
Flat button
Model:
LA42P-10/G
Order Number:
Description:
installation diameter 22mm, green, reset type, plastic, lamp holder rated voltage, flat head button, auxiliary contact 1NO
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Tayee | |
| Series： | LA42 | |
| Base Material： | plastic | |
| Light Source： | - | |
| Installation Diameter： | 22mm | |
| Color： | green | |
| Function： | Reset type | |
| Auxiliary Contacts： | 1NO | |
| Product Type： | Flat button |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Description
- The LA42 series button switches are high - quality products created by Tiandian Electric after more than ten years of technical accumulation. The unique product structure realizes the international common fastener - free self - locking connection, which is safe and reliable and easy to disassemble, fully reflecting the perfect combination of Tiandian's technology and innovation. The LA42 series buttons and indicators produced by Shanghai Tiandian Electric have complete specifications. The products use imported nylon, are firm and durable, wear - resistant, and the contacts have highly reliable contact, which can meet the different needs of users.
Applications
- The LA42 series buttons are suitable for control circuits with AC 50Hz (or 60Hz), voltage up to AC 600V and DC 400V, etc., for the interlocking use of control signals. The products are widely used in CNC machine tools, machinery, electric power, telecommunications, ships, metallurgy, chemical engineering and other industries.
Product Features
- The LA42 series buttons are divided into two categories: circular and square. The product varieties are rich and the specifications are complete, meeting the different needs of customers;
- The button surface is processed by special processing technology, with bright and eye - catching colors, no wear and no fading after long - term use;
- The decorative ring adopts the internationally popular matte metal treatment, which is high - grade and beautiful;
- The buttons are made of imported nylon material, with a flame retardant rating as high as V - 0, safe and reliable;
- The contacts adopt a modular structure, with flexible combination, simple disassembly and assembly, and safe and reliable wiring;
- The LA42 series buttons have a unique waterproof device, which ensures the high protection ability of the product. After adding a protective cover, the protection level can be as high as IP67;
- The LA42 series products have excellent anti - vibration performance and a long service life.
