ABB UA95-30-11
Brand:
Series:
UA
Switching Capacitor Capacity:
60/65kvar
Control Coil Voltage:
380-400VAC 50Hz/400-415VAC 60Hz
Auxiliary Contacts:
1NO+1NC
Rated Current:
95A
Model:
UA95-30-11 380-400V 50HZ/400-415V 60HZ(82204515)
Order Number:
10095783
Description:
ABB capacitor contactor UA95-30-11 380-400V 50HZ/400-415V 60HZ , auxiliary contact 1NO+1NC, switching capacitor capacity 60/65kvar, rated current 95A
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | ABB | |
| Series： | UA | |
| Switching Capacitor Capacity： | 60/65kvar | |
| Control Coil Voltage： | 380-400VAC 50Hz/400-415VAC 60Hz | |
| Auxiliary Contacts： | 1NO+1NC | |
| Rated Current： | 95A |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Scope of Application
- In low - voltage industrial control devices, capacitor banks are mainly used to improve the power factor of the power grid.
- At the moment when the capacitor bank is put into operation, there will be high - peak - value, high - frequency inrush current (3 - 15 KHz).
The peak value of the inrush current, that is, the maximum value of the inrush current, depends on the following factors:
- Grid inductive reactance
- Transformer capacity and short - circuit voltage
- Power factor correction scheme type
There are two power factor correction methods:
- Fixed type: All capacitors are controlled by one contactor to ensure simultaneous input (single - step). The peak value of the inrush current for fixed - type input can reach 30 times the normal working current of the capacitor bank.
- Automatic type: The power factor controller determines the power input at each step and controls the input of relevant capacitors (multi - step). The peak value of the inrush current for the automatic type depends on the power of the capacitors that have been put into operation, and can reach 100 times or more of the normal working current.
UA Three - Pole Contactor
- Suitable for single - stage or multi - stage capacitor banks for power compensation through switching.
- The maximum peak current is 100 times the effective current of the capacitor (at U e 500V) or 90 times (at U e 500V).
- Electrical service life: 100,000 times
Series Overview
Series Overview
Scope of Application
- In low - voltage industrial control devices, capacitor banks are mainly used to improve the power factor of the power grid.
- At the moment when the capacitor bank is put into operation, there will be high - peak - value, high - frequency inrush current (3 - 15 KHz).
The peak value of the inrush current, that is, the maximum value of the inrush current, depends on the following factors:
- Grid inductive reactance
- Transformer capacity and short - circuit voltage
- Power factor correction scheme type
There are two power factor correction methods:
- Fixed type: All capacitors are controlled by one contactor to ensure simultaneous input (single - step). The peak value of the inrush current for fixed - type input can reach 30 times the normal working current of the capacitor bank.
- Automatic type: The power factor controller determines the power input at each step and controls the input of relevant capacitors (multi - step). The peak value of the inrush current for the automatic type depends on the power of the capacitors that have been put into operation, and can reach 100 times or more of the normal working current.
UA Three - Pole Contactor
- Suitable for single - stage or multi - stage capacitor banks for power compensation through switching.
- The maximum peak current is 100 times the effective current of the capacitor (at U e 500V) or 90 times (at U e 500V).
- Electrical service life: 100,000 times
