Delixi CDC19S-95/12 50HZ 220/230V ROHS
Brand:
Series:
CDC19s
Switching Capacitor Capacity:
45kvar
Control Coil Voltage:
220VAC
Auxiliary Contacts:
1NO+2NC
Rated Current:
95A
Model:
CDC19S-95/12 50HZ 220/230V ROHS
Order Number:
CDC19S9512M
Description:
Delixi capacitor contactor CDC19S-95/12 50HZ 220/230V ROHS, auxiliary contact 1NO+2NC, switching capacitor capacity 45kvar, rated current 95A
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Delixi | |
| Series： | CDC19s | |
| Switching Capacitor Capacity： | 45kvar | |
| Control Coil Voltage： | 220VAC | |
| Auxiliary Contacts： | 1NO+2NC | |
| Rated Current： | 95A |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Overview
- The all - new CJX2s series of motor control and protection products adopt a new - generation technology platform and apply automated production and testing equipment, truly meeting customers' actual application needs and becoming easy - to - use and high - quality leading products in the country. This series includes six major series and their accessories: CJX2s AC contactors, JRS1Dsp thermal overload relays, JZC4s contactor - type relays, CDC19s capacitor - switching contactors, CDS2s electromagnetic starters, and CDV2s motor circuit breakers.
Product Range
- CDC19s capacitor - switching contactors: Current specifications cover 25 - 115A, and the controllable capacitor capacity is up to 60kvar
- Accessories: FC6 auxiliary contact heads
- Certifications: CCC, CE
Compliance with Standards
- GB/T14048.1 General Rules IEC60947 - 1 General Rules
- GB/T 14048.2 Circuit - breakers IEC60947 - 2
- GB/T14048.4 Contactors IEC60947 - 4 - 1 Contactors
- GB/T14048.5 Relays IEC60947 - 5 - 1 Relays
Normal Installation and Operation Conditions
-
Installation Position
- Should be mounted vertically on the installation surface, with the inclination in all directions not exceeding 22.5° (for JRS1Ds, not exceeding 5°); Installation category is Class III.
-
Pollution Degree
- Level 3
-
Ambient Temperature
- During normal operation, the ambient air temperature is not higher than + 40°C, not lower than - 5°C, and the 24 - hour average does not exceed + 35°C;
- Storage temperature: - 25°C ~ + 55°C, within a short time (24h), it can reach + 70°C
-
Altitude
- The altitude of the normal operation installation site does not exceed 2000m.
-
Humidity
- The relative humidity of the atmosphere does not exceed 50% when the surrounding maximum temperature is + 40°C, and can be relatively high at lower temperatures, such as 90% at 20°C.
- For condensation occasionally generated due to temperature changes, protective measures should be taken.
-
Product Protection Class
- IP20
Series Overview
Series Overview
Product Overview
- The all - new CJX2s series of motor control and protection products adopt a new - generation technology platform and apply automated production and testing equipment, truly meeting customers' actual application needs and becoming easy - to - use and high - quality leading products in the country. This series includes six major series and their accessories: CJX2s AC contactors, JRS1Dsp thermal overload relays, JZC4s contactor - type relays, CDC19s capacitor - switching contactors, CDS2s electromagnetic starters, and CDV2s motor circuit breakers.
Product Range
- CDC19s capacitor - switching contactors: Current specifications cover 25 - 115A, and the controllable capacitor capacity is up to 60kvar
- Accessories: FC6 auxiliary contact heads
- Certifications: CCC, CE
Compliance with Standards
- GB/T14048.1 General Rules IEC60947 - 1 General Rules
- GB/T 14048.2 Circuit - breakers IEC60947 - 2
- GB/T14048.4 Contactors IEC60947 - 4 - 1 Contactors
- GB/T14048.5 Relays IEC60947 - 5 - 1 Relays
Normal Installation and Operation Conditions
-
Installation Position
- Should be mounted vertically on the installation surface, with the inclination in all directions not exceeding 22.5° (for JRS1Ds, not exceeding 5°); Installation category is Class III.
-
Pollution Degree
- Level 3
-
Ambient Temperature
- During normal operation, the ambient air temperature is not higher than + 40°C, not lower than - 5°C, and the 24 - hour average does not exceed + 35°C;
- Storage temperature: - 25°C ~ + 55°C, within a short time (24h), it can reach + 70°C
-
Altitude
- The altitude of the normal operation installation site does not exceed 2000m.
-
Humidity
- The relative humidity of the atmosphere does not exceed 50% when the surrounding maximum temperature is + 40°C, and can be relatively high at lower temperatures, such as 90% at 20°C.
- For condensation occasionally generated due to temperature changes, protective measures should be taken.
-
Product Protection Class
- IP20
