TENGEN Accessories Coil CJX1-75 380V
Brand:
Series:
CJX1
Installation Location:
-
Control Coil Voltage:
380VAC
Auxiliary Contacts:
-
Product Type:
Contactor coil
Model:
Accessories coil CJX1-75 380V
Order Number:
150000172
Description:
TENGEN contactor accessories coil CJX1-75 380V, contactor coil, control coil voltage 380VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | TENGEN | |
| Series： | CJX1 | |
| Installation Location： | - | |
| Control Coil Voltage： | 380VAC | |
| Auxiliary Contacts： | - | |
| Product Type： | Contactor coil |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Product Overview
- The CJX1 series AC contactors are mainly used for AC 50Hz or 60Hz, with a rated insulation voltage of 660V.
- In the power line where the rated working voltage is 380V under the AC - 3 use category, the rated working current ranges from 9A to 475A.
- Used for remote connection and disconnection of circuits, and suitable for controlling the starting, stopping, and reversing of AC motors.
- Comply with standards: GB 14048.4, IEC 60947 - 4 - 1, and GB 21518.
Product Parameters
- Rated control power supply voltage (Us) of the coil: AC 380V, 220V, 127V, 110V, 48V, 36V, 24V;
DC 12V, 24V, 36V, 42V, 48V, 110V, 220V.
Normal Operating and Installation Conditions
- Ambient temperature: - 5°C~+40°C, and the average value within 24 hours does not exceed +35°C.
- Altitude: Not exceeding 2000m.
- Atmospheric conditions: When the maximum temperature is +40°C, the relative humidity of the air does not exceed 50%. Higher humidity is allowed at lower temperatures, and special measures should be taken for condensation occasionally generated due to temperature changes.
- Pollution level: Level 3.
- Installation category: Category III.
- Shock and vibration: The product should be installed and used in a place without significant shaking, impact, and vibration.
Structural Features
- The contactor is a direct - acting mechanism with double - break contacts, having three pairs of normally open main contacts.
- The contact supports of the contactor and the yoke are connected by elastic bolts, eliminating the thin - walled ring. The action mechanism is flexible, manual inspection is convenient, and the structural design is compact. It can prevent external debris and dust from falling into the active parts. The terminals have shields, and human hands cannot directly touch the live parts. The contactor has a small external size and a small installation area.
- The installation method can use guide rail installation or screw tightening. Compared with other similar products, it has a higher operating frequency and control capacity.
- The product is safe and reliable, and is an internationally advanced contactor mechanism.
Contact System
- The main and auxiliary contacts are made of silver alloys with excellent electrical properties, having a long service life and good contact reliability. The arc - extinguishing chamber is of a sealed type, and there are flame - retardant plastic materials to block the arc from splashing outward. For Ie ≤ 22A, there is an arc - extinguishing sheet without an arc; for Ie ≥ 32A, a metal arc - extinguishing plate is installed to ensure the safety of people and nearby electrical appliances.
- The terminal screws use new - type self - locking screws. The washer and the screw are inseparable, which can save time during installation.
Magnetic System
- The electromagnetic system works reliably, with low loss and low noise, and has very high mechanical strength. The terminals of the coil are equipped with nameplates marked with voltage specifications.
- The voltage levels marked on the nameplate are painted with specific colors, which are clear and eye - catching. Wiring is convenient, and it can avoid coil burnout caused by wrong connection of voltage specifications.
