TENGEN JZC1-44/Z DC48V Control Relay

Name: TENGEN JZC1-44/Z DC48V Control Relay
SKU: 03020010152

Brand:

TENGEN

Series:

JZC1

Control Voltage:

48VDC

Control Circuit:

AC 50/60Hz

Auxiliary Contacts:

4NO+4NC

Product Type:

AC control relay

Model:

JZC1-44/Z DC48V

Order Number:

03020010152

Description:

TENGEN control relay JZC1 JZC1-44/Z DC48V, AC control relay, control circuit AC 50/60Hz, auxiliary contact 4NO+4NC, control voltage 48VDC

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	TENGEN
Series：	JZC1
Control Voltage：	48VDC
Control Circuit：	AC 50/60Hz
Auxiliary Contacts：	4NO+4NC
Product Type：	AC control relay

Products with the same attribute : 0

Show details

Series Overview

Product Features

For AC operation of the relay, a straight - moving E - shaped iron core is used; for DC operation, a rotating U - shaped iron core is used. It has a double - break bridge - type straight - moving linkage structure, and the action is reliable.
The operating mechanism of the relay is flexible, and manual inspection is convenient. The structure is designed to be compact, which can prevent external debris and dust from falling into the moving parts of the relay. The wiring terminals are all equipped with protective covers, and human hands cannot directly touch the live parts, which can ensure safe use and meet the safe electricity use standards.
The external size of the relay is small, and the installation area is small. The installation method can be fastened with screws or clamped on a 35mm - wide standard installation guide rail, with the advantages of rapid and convenient assembly and disassembly.
The contacts have a bridge - type double - break structure. The contact materials are made of silver - nickel alloy with excellent electrical performance, which has a long service life and good contact reliability. The arc - extinguishing chamber is fully enclosed, and the arc - resistant material blocks the arc from splashing outward, ensuring the safety of personnel and nearby electrical appliances.
The electromagnet of the relay operates reliably, with low loss and low noise, and has very high mechanical strength. The terminal of the coil is equipped with a nameplate of the voltage specification, which is clear and eye - catching, and the wiring is convenient, which can avoid wrong connection of the voltage specification and cause the coil to burn out.
