Huyu HUCPS-45/16A 230V +G Control
Brand:
Series:
HUCPS
Control Coil Voltage:
230V
Auxiliary Contacts:
-
Rated Current:
16A
Rated Voltage:
690V
Model:
HUCPS-45/16A 230V +G
Order Number:
1330100051
Description:
Huyu HUCPS-45/16A 230V +G, control coil voltage 230V, rated current 16A, 690V
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Huyu | |
| Series： | HUCPS | |
| Should Be Occasion： | - | |
| Residual Current Protection： | - | |
| Control Coil Voltage： | 230V | |
| Auxiliary Contacts： | - | |
| Rated Current： | 16A | |
| Rated Voltage： | 690V |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Applications and Scope of Application
- The HUCPS series control and protection switching electrical appliance is mainly used in power systems with AC 50Hz (60Hz), rated voltage up to 690V, main rated current from 6.3A to 125A, digital controller adjustable working current from 0.16A to 125A, and controlled motor power from 0.05KW to 55kW. It is used to connect, carry and break currents under normal conditions (including specified overload conditions), and can also connect, carry and break currents under specified abnormal conditions (such as short circuits).
- The HUCPS series control and protection switching electrical appliance adopts a modular single - product structure type, integrating the main functions of traditional low - voltage electrical products such as circuit breakers (fuses), contactors, overload (or over - current, phase failure) protection electrical appliances, intelligent power comprehensive protectors, starters, isolators, and motor comprehensive protectors. It has remote automatic control and local direct - force control functions, with panel indication and electrical signal alarm functions, over - voltage and under - voltage protection functions, phase - breaking and phase - loss protection functions, and coordinated time - current protection characteristics (with three - stage protection characteristics of overload long - time delay, over - current short - time delay, and short - circuit instantaneous). According to needs, function modules or accessories can be selected, with protection functions (including short - circuit protection, overload protection, over - current protection, phase - breaking and phase - loss protection, over - voltage and under - voltage protection, three - phase unbalance protection, residual current protection, etc.) and control functions (including manual control, local control, remote control, fire - fighting automatic control, etc.). It can realize the control and protection of various motor loads (including infrequent starting, frequent starting) and distribution loads, providing a complete digital intelligent solution for customers with different needs.
Product Types
- Basic type product HUCPS configuration: main body, intelligent trip unit, auxiliary contact group.
- The electrical schematic diagram of the basic type product HUCPS can be found in the basic electrical schematic diagram below.
- Reversible control and protection switching electrical appliance HUCPSN: Using the HUCPS basic type as the main switch, combined with components such as mechanical interlocking and electrical interlocking, it forms a reversible control and protection switching electrical appliance, suitable for the reversible or bidirectional control and protection of motors.
- Dual - power automatic transfer switching electrical appliance HUCPS: For products with rated current 125A and below, the HUCPS basic type is used as the main switch and combined with accessories such as mechanical interlocking and electrical interlocking to form CB level or PC level dual - power automatic transfer switching electrical appliances. For products with rated current above 125A, the ATSE is used as the main switch.
- Reduced - voltage starting HUCPS, HUCPS2, HUCPS2, HUCPSR: Using the HUCPS basic type as the main switch, combined with appropriate contactors, time relays, mechanical interlocking and electrical interlocking to form Y - Δ reduced - voltage starters HUCPSJ, self - coupling reduced - voltage starters HUCPSZ, electronic reduced - voltage starters HUCPSR, realizing the reduced - voltage starting and multiple protections of motors.
- Double - speed controller HUCPSD: Using the HUCPS basic type as the main switch, combined with appropriate contactors, electrical interlocking and other accessories, it forms a double - speed controller, suitable for the control and protection of double - speed motors.
- Triple - speed controller HUCPSD3: Using the HUCPS basic type as the main switch, combined with appropriate contactors, electrical interlocking and other accessories, it forms a triple - speed controller, suitable for the control and protection of triple - speed motors.
- Enhanced function types: fire - fighting type (F type), isolation type (G type), leakage type (L type), communication type (T type), power distribution type (P type).
Applicable Fields
- The HUCPS series products have the advantages of integrated control and protection functions, modularization, miniaturization structure, high protection level against environmental pollution, high short - circuit current breaking capacity, long electrical life, complete protection functions, high continuous operation performance and reliability, convenient installation, use, maintenance and operation, etc. They are widely used in industrial facilities, infrastructure, fire - fighting systems, as well as commercial and civil facilities:
- Power distribution and motor protection and control systems in fields such as metallurgy, coal, steel, petrochemical, ports, ships, and railways;
- Motor control centers (MCC) and power distribution centers;
- Electrical control and protection systems such as lighting, power conversion, pumps, fans, air conditioners, fire - fighting in modern buildings;
- Remote control and lighting systems;
- Power plants and substations;
- Port and railway systems (such as airport terminals, railway and highway passenger transportation centers, etc.);
- Expressway lighting, ventilation systems;
- Military base control systems (such as border posts, radar stations, etc.);
- Fire - fighting pumps, fans in various venues;
- Hospitals;
- Commercial buildings (such as large shopping centers, supermarkets, etc.);
- Computer rooms;
- Information processing centers (such as municipal governments, banks, securities trading centers, etc.);
- Single - machine control and protection systems in factory workshops.
