LMK-0.66 0.5 class 300/5 30 type current transformer

Name: LMK-0.66 0.5 class 300/5 30 type current transformer
SKU: ICX-71391-38386

Brand:

Delixi

Series:

LMK

Rated Capacity:

5-3.75VA

Opening Type:

Ring

Current Transformation Ratio:

300/5

Perforation Size:

30mm

Accuracy Level:

Level 0.5

Product Type:

Closed

Rated Voltage:

660V

Model:

LMK-0.66 0.5 level 300/5 1 turn 30 type

Order Number:

ICX-71391-38386

Description:

Delixi LMK-0.66 0.5 grade 300/5 1 turn 30 type, accuracy level 0.5, closed type, perforation size 30mm, 660V

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Delixi
Series：	LMK
Rated Capacity：	5-3.75VA
Opening Type：	Ring
Current Transformation Ratio：	300/5
Perforation Size：	30mm
Accuracy Level：	Level 0.5
Product Type：	Closed
Rated Voltage：	660V

Products with the same attribute : 0

Show details

Series Overview

Product Features

The iron core of this type of transformer is a toroidal and rectangular core, and the secondary winding is evenly distributed along the circumference of the core. Polycarbonate (PC) material is used as the insulating shell of the transformer.
The middle window is for busbar threading.
The secondary winding of this type of transformer is evenly wound, with very small magnetic leakage, and has the advantages of stable performance, light weight, and convenient installation.
National standard: GB/T 20840.1&2
Accuracy class: 0.2, 0.5, 0.2S, 0.5S, 1
Rated voltage: 0.66kV
Rated primary current: 5–5000A
Rated secondary current: 5
Long-term operation at 110% of rated current is allowed.
The secondary winding is subjected to a power frequency voltage of 3kV to the ground for 1min without breakdown or flashover.
