LMZJ1-0.5 type 0.5 level 200/5F current transformer

Name: LMZJ1-0.5 type 0.5 level 200/5F current transformer
SKU: ICX-72090-39085

Brand:

Huyu

Series:

LMZJ1-0.5

Rated Capacity:

5VA

Opening Type:

Ring

Current Transformation Ratio:

200/5

Perforation Size:

29mm

Accuracy Level:

Level 0.5

Product Type:

Busbar type

Rated Voltage:

500VAC

Model:

LMZJ1-0.5 type 0.5 level 200/5F

Order Number:

ICX-72090-39085

Description:

Huyu LMZJ1-0.5 type 0.5 class 200/5F, accuracy level 0.5, busbar type, perforation size 29mm, 500VAC

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Huyu
Series：	LMZJ1-0.5
Rated Capacity：	5VA
Opening Type：	Ring
Current Transformation Ratio：	200/5
Perforation Size：	29mm
Accuracy Level：	Level 0.5
Product Type：	Busbar type
Rated Voltage：	500VAC

Products with the same attribute : 0

Show details

Series Overview

Scope of Application

The LMZ(J)1 - 0.5 series current transformers are mainly used indoors. They are suitable for use as current and electric energy measurement or relay protection in AC circuits with a rated voltage of 0.5kV and below and a rated frequency of 50Hz. The product is a cast - in - place current transformer, and its installation method adopts the base plate fixed installation method.
The product complies with GB/T20840.1, GB/T20840.2

Normal Working Conditions

Installation site: Indoor
Ambient temperature: Minimum temperature - 5°C, maximum temperature + 40°C
Humidity conditions: The average value of relative humidity measured within 24 hours does not exceed 95%, and the average value of relative humidity within one month does not exceed 90%
Altitude: Not exceeding 1000m
The ambient air is free of obvious dust, smoke, corrosive gases, steam or salt contamination
There is no serious vibration or jolt in the installation site
