Schneider closed ring current transformer TA30 inner diameter 30MM (50437)
Brand:
Series:
Vigirex
Rated Capacity:
65KVA
Opening Type:
Ring
Current Transformation Ratio:
1/1000
Perforation Size:
30mm
Accuracy Level:
-
Product Type:
Closed
Rated Voltage:
-
Model:
Closed ring current transformer TA30 inner diameter 30MM (50437)
Order Number:
ICX-72750-39745
Description:
Schneider closed ring current transformer TA30 inner diameter 30MM (50437), accuracy level -, closed, perforation size 30mm, -
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Schneider | |
| Series： | Vigirex | |
| Rated Capacity： | 65KVA | |
| Opening Type： | Ring | |
| Current Transformation Ratio： | 1/1000 | |
| Perforation Size： | 30mm | |
| Accuracy Level： | - | |
| Product Type： | Closed | |
| Rated Voltage： | - |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Matching Toroidal Current Transformers
Vigirex RH10, RH21, RH99, RHU and RMH relays can all be used with the following current transformers:
- Closed - type or split - type toroidal current transformers (Type A, Type OA)
- Type E toroidal current transformers (for existing facilities):
- TE (Ø30mm) and PE (Ø50mm): Fully compatible
- IE (Ø80mm), ME (Ø120mm) and SE (Ø200mm): The sensitivity of the Vigirex relay must be adjusted to a value ≥ 300mA.
Meeting the Requirements of Electrical Installations
- Closed - type toroidal current transformers are suitable for new equipment with a maximum current of up to 630A.
- Toroidal current transformers can be mounted on DIN rails, flat panels or racks, clamped on Vigirex cables or connected to cables.
- Split - type toroidal current transformers are suitable for existing systems with a maximum current of up to 400A and can be installed on flat panels or with support brackets.
- Rectangular current transformers are suitable for busbars in installations with a current ≤ 4000A.
Matching Rectangular Current Transformers
RH10, RH21, RH99 relays can be used with rectangular current transformers of 280×115mm and 470×160mm. The sensitivity of the Vigirex relay must be adjusted to a value ≥ 500mA. It has the ability to withstand large residual current faults. After multiple verifications, it ensures accurate measurement after large phase currents pass through the current transformer during short - circuits between phases and PE conductors.
Temperature Range
- Operating temperature range of toroidal current transformers:
- Type A and Type OA toroidal current transformers: - 35°C / + 70°C
- Rectangular current transformers: - 35°C / + 80°C
- Storage temperature range of toroidal current transformers:
- Type A and Type OA toroidal current transformers: - 55°C / + 85°C
- Rectangular current transformers: - 55°C / + 100°C
- Rectangular current transformers
