ABB GAE75-10-11 DC contactor

Name: ABB GAE75-10-11 DC contactor
SKU: 10114089

Brand:

ABB

Series:

GAE

Main Contacts:

1NO

Control Circuit:

Control Coil Voltage:

24VDC

Auxiliary Contacts:

1NO+1NC

Rated Current:

85A

Poles:

Rated Voltage:

440VDC

Model:

GAE75-10-11*24V DC

Order Number:

10114089

Description:

main contact 1NO, control coil voltage 24VDC, 1P, 85A, DC, rated voltage 440VDC, auxiliary contact 1NO+1NC

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	ABB
Series：	GAE
Main Contacts：	1NO
Control Circuit：	DC
Control Coil Voltage：	24VDC
Auxiliary Contacts：	1NO+1NC
Rated Current：	85A
Poles：	1P
Rated Voltage：	440VDC

Products with the same attribute : 0

Show details

Series Overview

GA75 and GAE75 contactors are specially designed for the on-off control of DC circuits.

DC arcs are more difficult to extinguish than AC arcs. When selecting contactors, the current and voltage to be interrupted and the L/R time constant of the controlled circuit must be considered.

GA75 and GAE75 are contactors with a block-type structure design.

Main Poles
- The arc-extinguishing covers equipped on GA75 and GAE75 contactors adopt permanent magnet technology specially for interrupting DC circuits.
- The three poles of the contactor are connected in series through two insulated connecting wires (25mm²).
- GA75 and GAE75 are "single-pole" products and must be connected correctly according to the polarity marked on the product terminals. To be precise, 1L1 is the positive terminal and 2T1 is the negative terminal.
- Note: The main contacts cannot be replaced.
Auxiliary Contacts: 1 side-mounted auxiliary contact module CAL5-11 (for GA75-10-11 and GAE75-10-11 types).
Control Circuits
- GA75: AC operation
- GAE75: DC operation
