DDS686-4G(A7) 220V 1.5(6)A Class 2 New Direct Energy Meter
Brand:
Series:
DDS686
Accuracy Level:
Meritorious Level 2
Current Specifications:
1.5-6A
Voltage Specifications:
220V
Opening Size:
141*99mm
Number Of Phases:
Single Phase
Dimensions:
Overall dimensions 160*112*60mm, electronic, opening size 141*99mm, 220V, 1.5-6A, active level 2, single phase
Product Type:
Electronic
Model:
DDS686-4G(A7) 220V 1.5(6)A 2-level new direct type
Order Number:
09030270066
Description:
Overall dimensions 160*112*60mm, electronic, opening size 141*99mm, 220V, 1.5-6A, active level 2, single phase
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | TENGEN | |
| Series： | DDS686 | |
| Accuracy Level： | Meritorious Level 2 | |
| Current Specifications： | 1.5-6A | |
| Voltage Specifications： | 220V | |
| Opening Size： | 141*99mm | |
| Number Of Phases： | Single Phase | |
| Dimensions： | Overall dimensions 160*112*60mm, electronic, opening size 141*99mm, 220V, 1.5-6A, active level 2, single phase | |
| Product Type： | Electronic |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
- The D08686 single - phase electronic watt - hour meter adopts large - scale integrated circuits and SMT technology. Key components are selected from international brands with long service lives. This greatly improves the reliability and service life of the product. The stepping motor drives a six - digit counter to accumulate and display electricity consumption, and power - off data is not lost. The photoelectric isolation pulse output detects signals, facilitating detection and function expansion.
Functions and Features
- Adopts a high - precision chip, capable of accurately measuring bidirectional active electrical energy.
- Has reliable starting and latent performance.
- The electric energy circuit board is all powered by a transformer, greatly improving the stability and service life of the electric meter.
- The working temperature range is wide, and accurate measurement can be achieved under the condition of - 45°C ~ 70°C.
- Has anti - harmonic wave and high - frequency pulse interference functions.
- Has protection measures against power grid impact (lightning strike).
- When communication is configured, the electric meter information (including electricity quantity, constant, meter number, etc.) can be read through an infrared or RS485 interface. The communication performance is stable, and the success rate of meter reading can reach 100%.
- Can be customized to have infrared or RS485 communication types according to customer requirements.
