Siemens 6SE6440-2UD13-7AA1 Engineering inverter MM440
Brand:
Series:
MM440
Remote Display Terminal:
-
Protection Level:
IP20
Control Panel:
Alternative
Communication Protocol:
USS
Voltage Level:
Three-phase 380-480VAC
Rated Power:
0.37KW
Applications:
Various engineering applications
Rated Current:
1.3A
Model:
6SE6440-2UD13-7AA1
Order Number:
6SE64402UD137AA1
Description:
Siemens 6SE6440-2UD13-7AA1, communication protocol USS, control panel optional, IP20, 1.3A, 0.37KW, three-phase 380-480VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | MM440 | |
| Remote Display Terminal： | - | |
| Protection Level： | IP20 | |
| Control Panel： | Alternative | |
| Communication Protocol： | USS | |
| Voltage Level： | Three-phase 380-480VAC | |
| Rated Power： | 0.37KW | |
| Applications： | Various engineering applications | |
| Rated Current： | 1.3A |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
Applications
- The MICROMASTER 440 frequency inverter is suitable for various variable - speed drive devices. Owing to its high flexibility, it can be applied in a wide range of fields.
- It is especially suitable for crane and hoist systems, stereoscopic warehousing systems, the food, beverage, and tobacco industries, as well as positioning systems in the packaging industry. These applications require the frequency inverter to have higher technical performance and faster dynamic response than conventional applications.
- A feature of the frequency inverter is that its equipment performance meets users' needs and it is easy to use. Its input power supply voltage range is wide, making it suitable for use worldwide.
Design
- The MICROMASTER 440 adopts a modular design. The operation panel and various modules are easy to replace.
International Standards
- The MICROMASTER 440 frequency inverter complies with the EU Low Voltage Directive requirements; the MM440 frequency inverter with a filter complies with the EU EMC Directive requirements.
- The MICROMASTER 440 frequency inverter has the CE mark.
- Passed UL and cUL certifications
- C - tick
Main Features
- Simple commissioning
- Modular structure, so its configuration has maximum flexibility
- 6 programmable, isolated digital inputs
- 2 assignable analog inputs (0V to 10V, 0mA to 20mA); they can also be used as the 7th and 8th digital inputs
- 2 programmable analog outputs (0mA to 20mA)
- 3 fully programmable relay outputs (30V DC / 5A, resistive load; 250V AC / 2A, inductive load)
- When using a relatively high switching frequency, the motor can run at low noise (in case of a relatively high switching frequency, it should be derated for use)
- Perfect frequency inverter and motor protection functions
Options (Overview)
- Class A/B EMC filters
- LC filters
- Line reactors
- Output reactors
- Sealing covers
- BOP basic operation panel for setting frequency inverter parameters
- AOP advanced operation panel with text display function in multiple languages
- Communication modules:
- PROFIBUS
- DeviceNet
- CANopen
- Pulse encoder/counter modules
- PC connection components
- Combination components for installing the operation panel on the control cabinet door
- PC commissioning tool, running in WINDOWS95/98 and NT/2000/XP Professional environments
- Integration with Drive ES TIA
Features of Mechanical Structure
- Modular design
- Operating temperature: 0.12kW to 75kW: - 10°C to + 50°C; 90kW to 200kW: 0°C to + 40°C
- Compact structure, high kW number of frequency inverters per unit space
- Convenient cable connection; power supply and motor connection wires are isolated from each other, achieving the best electromagnetic compatibility
- Detachable operation panel
- On the detachable I/O board, control terminal connections do not require screws
Features of Control Performance
- The latest IGBT technology
- Controlled by a digital signal processor
- High - quality vector control system
- Flux - current control (FCC) improves dynamic response and optimizes motor control
- Linear V/F characteristics
- Square V/F characteristics
- Multi - point V/f characteristics (programmable V/F characteristics)
- Torque control
- Catch - up restart
- Slip compensation
- Automatic restart after power failure or fault clearance
- User - definable free - function blocks to implement logic and arithmetic operations
- Dynamic buffering
- Deceleration ramp function curves for positioning control
- The frequency inverter has a built - in high - quality PID controller (with parameter autotuning function), which can be used for general process control
- Programmable acceleration/deceleration ramp functions, 0 to 650 seconds
- Smooth function at the start and end segments of the ramp
- Fast current limitation (FCL) function, avoiding unnecessary trips during operation
- Fast and repeatable digital input response time
- Use two high - resolution 10 - bit binary analog inputs to achieve speed fine - tuning
- Composite braking, achieving fast braking control
- Integrated braking chopper (only for 0.12kW to 75kW frequency inverters)
- 4 skip frequencies
- Detachable Y - shaped DC - link capacitors, can be used in power supply systems with ungrounded neutrals (when powered by an ungrounded power supply, the Y - shaped DC - link capacitors must be removed and output reactors must be installed)
Protection Functions
- Overload Capacity
- CT Mode
- 0.12kW to 75kW:
- CT Mode
Overload current:
1.5x rated output current (i.e., 150% overload) for 60 seconds, repeat cycle time 300 seconds; and 2.0x rated output current (i.e., 200% overload) for 35 seconds, repeat cycle time 300 seconds.
- 90kW to 200kW:
Overload current:
1.36x rated output current (i.e., 136% overload) for 575 seconds, repeat cycle time 300 seconds; 1.6x rated output current (i.e., 160% overload) for 35 seconds, repeat cycle time 300 seconds.
- VT Mode
- 5.5kW to 90kW:
Overload current:
1.4x rated output current (i.e., 140% overload) for 35 seconds, repeat cycle time 300 seconds; and 1.1x rated output current (i.e., 110% overload) for 605 seconds, repeat cycle time 300 seconds.
- 110kW to 250kW:
Overload current:
1.5x rated output current (i.e., 150% overload) for 15 seconds, repeat cycle time 300 seconds; 1.1x rated output current (i.e., 110% overload) for 595 seconds, repeat cycle time 300 seconds.
- Overvoltage/Undervoltage Protection
- Frequency Inverter Over - temperature Protection
- Motor Over - temperature Protection via PTC through Digital Input
- Ground Fault Protection
- Short - circuit Protection
- I²t Motor Over - temperature Protection
- Motor Lock - up Protection
- Prevent Motor Overspeed
- Parameter Interlock
