RE28P-4EK.4I.1R Ziehl-Abegg Axial Fan
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | ZIEHL-ABEGG | |
| Type： | Axial Fan | |
| Max. Air Flow： | 680 m³/h | |
| Voltage Type： | AC | |
| Degree of Protection： | IP54 | |
| Conformity with Standards： | CE | |
| Motor Bearing： | Ball Bearing | |
| Direction of Rotation： | Clockwise | |
| Airflow Direction： | V | |
| Length： | ∅280 mm | |
| Noise： | 58 dB | |
| Max. Ambient Temperature： | 60 ℃ | |
| Min. Ambient Temperature： | -25 ℃ | |
| Input Power： | 690 W | |
| Speed： | 1360 RPM | |
| Voltage： | 230 V | |
| Series： | RE28P |
Application scenarios
-
Condensers
In the condenser, the fan (especially the fan in the air-cooled condenser) is a key component to accelerate heat dissipation, improve energy efficiencSee more -
Evaporators
The fan is a key component in the evaporator to enhance heat exchange, optimize energy efficiency and ensure stable operation, especially in scenariosSee more -
Condenser units
The condenser units consist of a condenser, a compressor and other refrigeration circuits or closed-loop control components. The gaseous refrigerant iSee more -
Tunnel Ovens
The fan achieves precise temperature control and uniform heating through high-speed circulation in the tunnel oven. Its forced airflow penetrates theSee more
Frequently asked questions
-
Characteristics and classification of axial flow fans
Axial flow fans are usually installed on the cabinets of electrical equipment, and sometimes integrated on the motor. Due to their compact structure, axial flow fans can save a lot of space and are easy to install, so they are widely used.
As the name implies, the airflow of the axial flow fan is axial movement. It is characterized by simple structure, low noise, large air volume, but can withstand low wind pressure. Therefore, the axial flow fan is suitable for ventilation and heat dissipation, which requires large air volume and low wind pressure.
According to the classification of wind direction: it can be divided into A (stator side to rotor side blowing) and V (rotor side to stator side blowing)
EBM has derived multiple series according to the structure of the axial flow fan:
Ebm A series: It is composed of motor plus blades
Ebm S series: It is composed of motor plus blades and mesh cover
Ebm W series: It is composed of motor plus blades and wind tube
A, S, W series fans are universal, and can also be equipped with accessories separately. For example, our friend's fan is S or W, with a mesh cover or wind tube. If the fan inside is broken, you can directly replace the A series motor plus blade fan, which can also save costs.
