CJTHT-125-6T/6-10 IE3 SODECA Smoke Extract Fans

Name: CJTHT-125-6T/6-10 IE3 SODECA Smoke Extract Fans
SKU: icx-SODECA-CJTHT-125-6T/6-10 IE3

Brand:

SODECA

Type:

Smoke Extract Fans

Max. Air Flow:

72650 m³/h

Blade Tilt Angle:

20 °

Installed Power:

7.5 KW

Noise:

74 dB

Speed:

960 RPM

Model:

CJTHT-125-6T/6-10 IE3

Order Number:

icx-SODECA-CJTHT-125-6T/6-10 IE3

Description:

SODECA CJTHT-125-6T/6-10 IE3, Smoke Extract Fans, Speed：960 RPM, Installed Power：7.5 KW, Max. Air Flow：72650 m³/h, Noise：74 dB

WhatsApp Inquire Now

Product parameters
Product Overview
File
Application scenarios

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	SODECA
Type：	Smoke Extract Fans
Max. Air Flow：	72650 m³/h
Blade Tilt Angle：	20 °
Installed Power：	7.5 KW
Maximum admissible current (A)-690V：	8.83 A
Maximum admissible current (A)-230V：	15.2 A
Noise：	74 dB
Speed：	960 RPM
Series：	CJTHT

Products with the same attribute : 0

Show details

Product Overview

Extraction units with axial fans to work immersed in fire risk areas.

Fan:
• Fan with tubular sheet steel casing.
• Galvanised sheet steel structure with thermal insulation and acoustic insulation.
• Variable angle impeller made of cast aluminium.
• Approved in accordance with standard EN 12101-3, with certifications no.: 0370-CPR-0305 (F400) and 0370-CPR-0973 (F300).

Motor:
• Class H motors for S1 continuous operation and S2 emergency use. With ball bearings, IP55 protection and 1 or 2 speeds, depending on model.
• Motors with IE3 efficiency for powers equal to or greater than 0.75 kW, except single-phase, 2-speed and 8-pole.
• Three-phase with IE4 efficiency for power from 75 kW to 200 kW, except 2-speed and 8-pole.
• Three-phase 230/400 V 50 Hz (up to 3 kW) and 400/690 V 50 Hz (powers greater than 3 kW).
• Maximum temperature of air to be carried: S1 -25 ºC +40 ºC continuous service, also suitable for warm climates with temperatures up to 50 ºC. S2 operation, 300 ºC/2h, 400 ºC/2h.

Finish:
• Fan: Anti-corrosive in polyester resin polymerized at 190 ºC, after degreasing with phosphate-free nanotechnological treatment.
• Box: Galvanised sheet steel.

Available versions:
• CJTHT/ATEX: Axial fans with acoustically insulated boxes and ATEX certification, category 3 Ex II3G for zone 2.
• CJTHT/PLUS: Axial fans with acoustic attenuators.

On request:
• Airflow direction from impeller to motor.
• 100% reversible impellers.
