CJTHT/ATEX-63-6/12T-1/CAT3 SODECA Smoke Extract Fans

Name: CJTHT/ATEX-63-6/12T-1/CAT3 SODECA Smoke Extract Fans
SKU: icx-SODECA-CJTHT/ATEX-63-6/12T-1/CAT3

Brand:

SODECA

Type:

Smoke Extract Fans

Max. Air Flow:

15890/7700 m³/h

Blade Tilt Angle:

38 °

Installed Power:

0.80/0.20 KW

Noise:

58/43 dB

Speed:

935/455 RPM

Model:

CJTHT/ATEX-63-6/12T-1/CAT3

Order Number:

icx-SODECA-CJTHT/ATEX-63-6/12T-1/CAT3

Description:

SODECA CJTHT/ATEX-63-6/12T-1/CAT3, Smoke Extract Fans, Speed：935/455 RPM, Installed Power：0.80/0.20 KW, Max. Air Flow：15890/7700 m³/h, Noise：58/43 dB

WhatsApp Inquire Now

Product parameters
Product Overview
File
Application scenarios

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	SODECA
Type：	Smoke Extract Fans
Max. Air Flow：	15890/7700 m³/h
Blade Tilt Angle：	38 °
Installed Power：	0.80/0.20 KW
Maximum admissible current (A)-400V：	3.75/2.76 A
Noise：	58/43 dB
Speed：	935/455 RPM
Series：	CJTHT/ATEX

Products with the same attribute : 0

Show details

Product Overview

Extraction units with axial fans to work immersed in fire risk areas and ATEX 3G certification for zone 2.

Fan:
• Fan with tubular sheet steel casing.
• Galvanised sheet steel structure with thermal insulation and acoustic insulation.
• Variable angle impeller made of cast aluminium.
• Approved in accordance with standard EN 12101-3, with certifications no.: 0370-CPR-0305 (F400) and 0370-CPR-0973 (F300).

Motor:
• Class H motors for S1 continuous operation and S2 emergency use. With ball bearings, IP55 protection and 1 or 2 speeds, depending on model.
• Motors with IE3 efficiency for powers equal to or greater than 0.75 kW, except single-phase, 2-speed and 8-pole.
• Three-phase with IE4 efficiency for power from 75 kW to 200 kW, except 2-speed and 8-pole.
• Three-phase 230/400 V 50 Hz (up to 3 kW) and 400/690 V 50 Hz (powers greater than 3 kW).
• Maximum temperature of air to be carried: S1 -20 ºC +40 ºC continuous service, also suitable for warm climates with temperatures up to 50 ºC. S2 operation, 300 ºC/2h, 400 ºC/2h.

Finish:
• Fan: Anti-corrosive in polyester resin polymerized at 190 ºC, after degreasing with phosphate-free nanotechnological treatment.
• Box: Galvanised sheet steel.

Available versions:
• CJTHT: Axial fans with acoustically insulated boxes.
• CJTHT/PLUS: Axial fans with acoustic attenuators.

On request:
• Airflow direction from impeller to motor.
• 100% reversible impellers.

File

CJTHT_ATEX_EN_v3.pdf
