CJTHT/PLUS-90-6T-4 IE3 SODECA Smoke Extract Fans

Name: CJTHT/PLUS-90-6T-4 IE3 SODECA Smoke Extract Fans
SKU: icx-SODECA-CJTHT/PLUS-90-6T-4 IE3

Brand:

SODECA

Type:

Smoke Extract Fans

Max. Air Flow:

38900 m³/h

Blade Tilt Angle:

30 °

Installed Power:

3 KW

Noise:

69 dB

Speed:

945 RPM

Model:

CJTHT/PLUS-90-6T-4 IE3

Order Number:

icx-SODECA-CJTHT/PLUS-90-6T-4 IE3

Description:

SODECA CJTHT/PLUS-90-6T-4 IE3, Smoke Extract Fans, Speed：945 RPM, Installed Power：3 KW, Max. Air Flow：38900 m³/h, Noise：69 dB

WhatsApp Inquire Now

Product parameters
Product Overview
File
Application scenarios
frequently asked questions

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	SODECA
Type：	Smoke Extract Fans
Max. Air Flow：	38900 m³/h
Blade Tilt Angle：	30 °
Installed Power：	3 KW
Maximum admissible current (A)-400V：	6.36 A
Maximum admissible current (A)-230V：	12.8 A
Noise：	69 dB
Speed：	945 RPM
Series：	CJTHT/PLUS

Products with the same attribute : 0

Show details

Product Overview

Extraction units with axial fans to work immersed in fire risk areas.

Fan:
• Fan with tubular sheet steel casing.
• Galvanised sheet steel structure with thermal insulation and acoustic insulation.
• Variable angle impeller made of cast aluminium.
• Approved in accordance with standard EN 12101-3, with certifications no.: 0370-CPR-0305 (F400) and 0370-CPR-0973 (F300).

Motor:
• Class H motors for S1 continuous operation and S2 emergency use. With ball bearings, IP55 protection and 1 or 2 speeds, depending on model.
• Motors with IE3 efficiency for powers equal to or greater than 0.75 kW, except single-phase, 2-speed and 8-pole.
• Three-phase 230/400 V 50 Hz (up to 3 kW) and 400/690 V 50 Hz (powers greater than 3 kW).
• Maximum temperature of air to be carried: S1 -25 ºC +40 ºC continuous service, also suitable for warm climates with temperatures up to 50 ºC. S2 operation, 300 ºC/2h, 400 ºC/2h.

Finish:
• Fan: Anti-corrosive in polyester resin polymerized at 190 ºC, after degreasing with phosphate-free nanotechnological treatment.
• Box: Galvanised sheet steel.

Available versions:
• CJTHT: Axial fans with acoustically insulated boxes.
• CJTHT/ATEX: Axial fans with acoustically insulated boxes and ATEX certification, category 3 Ex II3G for zone 2.

On request:
• Airflow direction from impeller to motor.
• 100% reversible impellers.
