Cl-50-4T SODECA Smoke Extract Fans

Name: Cl-50-4T SODECA Smoke Extract Fans
SKU: icx-SODECA-Cl-50-4T

Brand:

SODECA

Type:

Smoke Extract Fans

Max. Air Flow:

6050 m³/h

Impulsion speed (m/s):

23.5 m/s

Installed Power:

1.2 KW

Noise:

64 dB

Speed:

1395 RPM

Model:

Cl-50-4T

Order Number:

icx-SODECA-Cl-50-4T

Description:

SODECA Cl-50-4T, Smoke Extract Fans, Speed：1395 RPM, Installed Power：1.2 KW, Max. Air Flow：6050 m³/h, Noise：64 dB

WhatsApp Inquire Now

Product parameters
Product Overview
File
Application scenarios

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	SODECA
Type：	Smoke Extract Fans
Max. Air Flow：	6050 m³/h
Impulsion speed (m/s)：	23.5 m/s
Thrust：	50 N
Installed Power：	1.2 KW
Maximum admissible current (A)-400V：	2.9 A
Maximum admissible current (A)-230V：	5 A
Noise：	64 dB
Speed：	1395 RPM
Series：	CI

Products with the same attribute : 0

Show details

Product Overview

Fan:
• Sheet steel casing.
• Backward curved impeller in highly robust sheet steel.
• IAT series safety switch built into the fan.
• Fixing feet included.

Motor:
• Class H motors for S1 continuous operation and S2 emergency use. With ball bearings, IP55 protection and 1 or 2 speeds, depending on model.
• Three-phase 230/400 V 50 Hz.
• Maximum temperature of air to be carried: S1 -25 ºC +40 ºC continuous service, also suitable for warm climates with temperatures up to 50 ºC. S2 operation, 300 ºC/2h, 400 ºC/2h.

Finish:
• Anti-corrosive finish in polyester resin, polymerised at 190 ºC, after degreasing with phosphate-free nanotechnology treatment.

File

CI_EN_v2.pdf
