HTMF-56-4/8T-1.5 SODECA Smoke Extract Fans

Name: HTMF-56-4/8T-1.5 SODECA Smoke Extract Fans
SKU: icx-SODECA-HTMF-56-4/8T-1.5

Brand:

SODECA

Type:

Smoke Extract Fans

Max. Air Flow:

11530/5620 m³/h

Installed Power:

1.10/0.25 KW

Noise:

55/39 dB

Speed:

1420/695 RPM

Model:

HTMF-56-4/8T-1.5

Order Number:

icx-SODECA-HTMF-56-4/8T-1.5

Description:

SODECA HTMF-56-4/8T-1.5, Smoke Extract Fans, Speed：1420/695 RPM, Installed Power：1.10/0.25 KW, Max. Air Flow：11530/5620 m³/h, Noise：55/39 dB

WhatsApp Inquire Now

Product parameters
Product Overview
File
Application scenarios

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	SODECA
Type：	Smoke Extract Fans
Max. Air Flow：	11530/5620 m³/h
Installed Power：	1.10/0.25 KW
Maximum admissible current (A)-400V：	2.69/1.12 A
Noise：	55/39 dB
Speed：	1420/695 RPM
Series：	HTMF

Products with the same attribute : 0

Show details

Product Overview

400 ºC/2h and 300 ºC/2h rated roof mounted multifunctional extract fans for work in fire risk zones, designed for smoke extraction in industrial or similar buildings.

Fan:
• Support base in painted galvanised steel sheet.
• Adjustable cast aluminum impeller.
• Protection grid against contacts according to UNE-EN ISO 12499.
• Cap in painted galvanised steel sheet, with natural air outlet. Approval according to EN 12101-3, with certifications No. 0370-CPR-0305 (F400) and 0370-CPR-0973 (F300).

Motor:
• Class H motors for S1 continuous operation and S2 emergency use. With ball bearings, IP55 protection and 1 or 2 speeds, depending on model.
• Motors with IE3 efficiency for powers equal to or greater than 0.75 kW, except single-phase, 2-speed and 8-pole.
• Three-phase 230/400 V 50 Hz (up to 3 kW) and 400/690 V 50 Hz (powers greater than 3 kW).
• Maximum temperature of air to be carried: S1 -25 ºC +40 ºC continuous service, also suitable for warm climates with temperatures up to 50 ºC. S2 operation, 300 ºC/2h, 400 ºC/2h.

Finish:
• Anti-corrosive finish in polyester resin, polymerised at 190 ºC, after degreasing with phosphate-free nanotechnology treatment.
