THT/IMP-C-UNI-71-4T-4 IE3 SODECA Smoke Extract Fans

Name: THT/IMP-C-UNI-71-4T-4 IE3 SODECA Smoke Extract Fans
SKU: icx-SODECA-THT/IMP-C-UNI-71-4T-4 IE3

Brand:

SODECA

Type:

Smoke Extract Fans

Max. Air Flow:

28550 m³/h

Impulsion speed (m/s):

20 m/s

Installed Power:

3 KW

Noise:

65 dB

Speed:

1455 RPM

Model:

THT/IMP-C-UNI-71-4T-4 IE3

Order Number:

icx-SODECA-THT/IMP-C-UNI-71-4T-4 IE3

Description:

SODECA THT/IMP-C-UNI-71-4T-4 IE3, Smoke Extract Fans, Speed：1455 RPM, Installed Power：3 KW, Max. Air Flow：28550 m³/h, Noise：65 dB

WhatsApp Inquire Now

Product parameters
Product Overview
File
Application scenarios

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	SODECA
Type：	Smoke Extract Fans
Max. Air Flow：	28550 m³/h
Impulsion speed (m/s)：	20 m/s
Thrust：	182 N
Installed Power：	3 KW
Maximum admissible current (A)-400V：	6.33 A
Maximum admissible current (A)-230V：	11.01 A
Noise：	65 dB
Speed：	1455 RPM
Series：	TUNEL JET FAN

Products with the same attribute : 0

Show details

Product Overview

Unidirectional jet fans, very robust with cast aluminum impeller for medium thrust. Specially designed for tunnel ventilation and smoke evacuation in case of fire, certified 400 ºC/2h and 300 ºC/2h according to model.

Fan:
• Large thickness tubular sheet steel casing.
• Motor support welded to the casing.
• Aerodynamic inlet and discharge cone.
• Optimal surface protection by high quality steel.
• One way impeller made of cast aluminium.
• Tubular silencer coupled to both ends that provides high thermal and acoustic insulation.
• Support base specially designed to support the entire set. From the 560 mm diameter it incorporates anti-vibration springs.
• Electrical connection in external terminal box.
• E90 cable with metal protection.
• Support feet or support bench depending on the model included in the set.
• Vibration isolators.
• Security anchor included.
• Approved in accordance with standard EN 12101-3.

Motor:
• Class H motors for S1 continuous operation and S2 emergency use. With ball bearings and IP55 protection.
• Motors with IE3 efficiency for powers equal to or greater than 0.75 kW, except single-phase, 2-speed and 8-pole.
• Three-phase 400/690 V 50 Hz.
• Maximum temperature of air to be carried: S1 -25 ºC +40 ºC continuous service, also suitable for warm climates with temperatures up to 50 ºC. S2 operation, 300 ºC/2h, 400 ºC/2h.

Finish:
• High protection anti-corrosive steel, special primer and high quality paint for corrosive atmospheres.

On request:
• IP55 standard motors, ATEX and 2 speed motors.
• Total stainless steel construction.
• Hot dip galvanised steel construction.
