THT/IMP-O-UNI-45-2/4T-2 SODECA Smoke Extract Fans

Name: THT/IMP-O-UNI-45-2/4T-2 SODECA Smoke Extract Fans
SKU: icx-SODECA-THT/IMP-O-UNI-45-2/4T-2

Brand:

SODECA

Type:

Smoke Extract Fans

Max. Air Flow:

10800/5375 m³/h

Impulsion speed (m/s):

18.1/9.0 m/s

Installed Power:

1.50/0.37 KW

Noise:

57/41 dB

Speed:

2875/1430 RPM

Model:

THT/IMP-O-UNI-45-2/4T-2

Order Number:

icx-SODECA-THT/IMP-O-UNI-45-2/4T-2

Description:

SODECA THT/IMP-O-UNI-45-2/4T-2, Smoke Extract Fans, Speed：2875/1430 RPM, Installed Power：1.50/0.37 KW, Max. Air Flow：10800/5375 m³/h, Noise：57/41 dB

WhatsApp Inquire Now

Product parameters
Product Overview
File
Application scenarios

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	SODECA
Type：	Smoke Extract Fans
Max. Air Flow：	10800/5375 m³/h
Impulsion speed (m/s)：	18.1/9.0 m/s
Thrust：	62/31 N
Installed Power：	1.50/0.37 KW
Maximum admissible current (A)-400V：	3.58/1.19 A
Noise：	57/41 dB
Speed：	2875/1430 RPM
Series：	THT/IMP

Products with the same attribute : 0

Show details

Product Overview

300 ºC/2h and 400 ºC/2h long range unidirectional or reversible jet fans with a circular design (THT/IMP-C), octogonal design (THT/IMP-L) or octogonal painted design (THT/IMP-O).

Fan:
• Unidirectional or reversible fan assembly consisting of fan, silencers, deflectors and supports, approved for smoke evacuation, according to EN 12101-3, with certifications No.: 0370-CPR-0305 (F400) and 0370-CPR-0973 (F300 ).
• Adjustable cast aluminum impeller designed to obtain high thrusts.
• Protection grid against contacts according to the UNE-EN ISO 12499 standard in unidirectional models.
• Deflector for increased air reach, on the outlet side. Reversible models are equipped with deflectors on both sides.
• High attenuation silencers with thermal and acoustic insulation.
• IAT series safety switch built into the fan (THT/IMP-L and THT/IMP-O) or on request (THT/IMP-C).
• Airflow direction from motor to impeller or 100% reversible.
• THT/IMP-C: Painted sheet steel circular casing.
• THT/IMP-L: Galvanised sheet steel casing.
• THT/IMP-O: Painted sheet metal casing.
• THT/IMP-LS: Casing of reduced length, in galvanised sheet steel.

Motor:
• Class H motors for continuous use S1 and emergency use S2. With ball bearings, IP55 protection and 2 speeds.
• Three-phase 400 V 50 Hz DAHLANDER.
• Maximum temperature of air to be carried: S1 -25 ºC +40 ºC continuous service, also suitable for warm climates with temperatures up to 50 ºC. S2 operation, 300 ºC/2h, 400 ºC/2h.

Finish:
• Anti-corrosive in polyester resin polymerized at 190 ºC, after degreasing with phosphate-free nanotechnological treatment (THT/IMP-C, THT/IMP-O) or galvanised steel sheet (THT/IMP-L).

On request:
• Thrust performance other than those indicated.

File

THT_IMP_EN_v2.pdf
