Home HVAC Ventilation Equipment Ventilation and Cooling Fan

THT/WALL/IE5 SODECA Smoke Extract Fans

Name: THT/WALL/IE5 SODECA Smoke Extract Fans
SKU: icx-SODECA-THT/WALL/IE5

Brand:

SODECA

Type:

Smoke Extract Fans

Model:

THT/WALL/IE5

Order Number:

icx-SODECA-THT/WALL/IE5

Description:

SODECA THT/WALL/IE5, Smoke Extract Fans

WhatsApp Inquire Now

Product parameters
Product Overview
File
Application scenarios

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	SODECA
Type：	Smoke Extract Fans
Series：	THT/WALL/IE5

Products with the same attribute : 0

Show details

Product Overview

Wall-mounted dynamic extractors exhaust fans with motorized hatch and ultra-high efficiency IE5 motor, with option for connection to an extraction duct. Specially designed for fast and effective evacuation of smoke and toxic gases in the event of a fire. Suitable for installation in industrial buildings, commercial facilities, or any other type of construction. Can be used for ambient ventilation.

Fan:
• Helicoidal casing support and fixing flange to allow easy wall anchorage and installation.
• Certified according to EN 12101-3, F400 classification.
• Tubular casing in sheet steel with polyester resin anti-corrosive treatment.
• Variable angle impeller made of cast aluminium.
• Shielded power cable with EMC protection.
• Airflow direction from motor to impeller.

Extruded aluminum hatch:
• An extremely robust structure that is able to withstand severe weather changes.
• Designed to ensure watertightness.
• Aluminum profile with thermal bridge break.
• Central ceiling and structure equipped with high performance thermal insulation.
• Thermal resistance of the assembly less than 0.89 W/m²·K.
• Position indicators in both positions (open and closed).
• Upper and lower opening mounting versions.
• Manual opening system.
• Airborne acoustic insulation value according to UNE-EN ISO 10140-2: Rw = 27 (0;-2) dB.

Motor:
• Class H motors for continuous use (S1) and emergency use (S2). With ball bearings, IP55 protection, and single speed.
• IE5 efficiency motors.
• Three-phase 230/400 V 50 Hz (up to 3 kW) and 400/690 V 50 Hz (powers greater than 3 kW).
• Maximum air temperature: Service S1 -25 ºC to +40 ºC continuously, also suitable for hot climates up to 50 ºC. Service S2 400 ºC/2h.

Actuator:
• Reliability greater than 20,000 dual cycles.
• Supply voltage at 230 V AC 50/60 Hz.
• Working temperature: -25 ºC +60 ºC.
• Protection at the leading edge when closing the hatch.
• The stop in the closed position is regulated by an electronic limit switch.

Hatch finish:
• Anti-corrosive in extruded aluminum.
• RAL 7016 supplied as standard. Any other RAL can be supplied on demand.

On request:
• Actuator with 24 V DC supply voltage.
