Schneider MVS10N3F504 frame circuit breaker

Name: Schneider MVS10N3F504 frame circuit breaker
SKU: MVSN103

Brand:

Schneider

Wiring Method:

Up and down horizontal wiring

Trip Unit:

Trip System 5.0S

Model:

MVS10N3F504

Order Number:

MVSN103

Description:

SchneiderMVS10N3F504,55KA,1000A,Trip System 5.0S,Fixed,220-440VAC,3P

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	MVS
Protection Function：	LSI
Configured Attachments：	Opening coil, closing coil, energy storage motor, auxiliary contact 4NO+4NC, door frame, fault trip indication contact
Frame Current：	1000A
Wiring Method：	Up and down horizontal wiring
Poles：	3P
Rated Voltage：	220-440VAC
Installation：	Fixed
Trip Unit：	Trip System 5.0S
Rated Current of Release：	1000A
Breaking Capacity：	55KA
Measurement Display Function：	-
Required Accessories (please purchase separately)：	-

Products with the same attribute : 0

Show details

Series Overview

Three breaking models with three breaking capacities:

Type N, H, T: Suitable for building power distribution systems and industrial applications. Ics = 100% Icu, meaning the service breaking capacity equals the ultimate breaking capacity. After experiencing fault current, the system requires no component replacement, meeting stricter demands for breaking capacity and power supply continuity (Icu = Ics = Icw (1s)).

EasyPact MVS offers higher short-time withstand capacity, fully satisfying selectivity requirements.

Equal values of the three parameters maximize system stability and reliability.
Significantly reduces user operating costs and improves economic efficiency.
Patented arc extinguishing technology achieves true zero arc flash, ensuring operator safety and enhancing system security.
Zero safety distance increases power distribution cabinet utilization.

Innovative Design and Technological Upgrades

Today, advancements in computer technology and miniaturized storage devices have enriched control unit functionalities, including:

Precise measurement of system parameters.
Protection function calculations.
Data storage, event logging, alarm signaling, and more.

The new MVS Trip System series offers 7 models, providing EasyPact MVS with highly reliable protection and precision measurement displays.

Highly Integrated and Intelligent

The EasyPact MVS control unit integrates comprehensive parameter measurement and event programming, simplifying installation and maintenance while reducing costs.
The intelligent Trip System features event recording and maintenance diagnostics, enabling system monitoring and optimized maintenance planning.

Reliable Measurement and User-Friendly Interface

Equipped with a digital LCD screen and intuitive navigation keys.
Directly displays electrical parameters (current, voltage, etc.).
Allows adjustment and reading of protection parameters.

Cost Efficiency

Flexible configurations and strong scalability meet diverse user needs.
Compact size saves design and installation space.
Universal accessories minimize inventory requirements.
Modular design lowers procurement costs.

Streamlined Ordering and Seamless Experience

EasyPact MVS air circuit breakers simplify the entire project lifecycle, from design and configuration to operation and maintenance.

Key Highlights

Reliable Performance: Covers 400–4000A range.
Cost-Effective: Excellent value, easy ordering.
Consistent Quality: Classic structural design, advanced manufacturing processes, and eco-friendly materials.

Circuitbreaker Overview

Range:

EasyPact MVS 400–1600A (Type N)
EasyPact MVS 630–4000A (Type H)
EasyPact MVS 2000–4000A (Type T)

Models: N, H, T

Poles: 3 or 4

Installation: Fixed or withdrawable

Derating Protection: Supported

Frame Sizes: Only 2 options

Reverse Feeding: Maintains performance.

Rachel

Industrial Control Sales Specialist: Focuses on delivering high-performance, cost-effective industrial control products. Offers end-to-end one-stop procurement support—covering rapid quotation, streamlined order fulfillment, and responsive after-sales service—to simplify clients’ procurement processes. Email: Anthony@icxsg.com

We offer competitive product pricing. For fast support, send your email, phone, address, and the product model & quantity you want—we’ll reach out quickly!

We typically respond via email within one business day! You can also contact us at Anthony@icxsg.com

Message*

email*

address

File upload：

Upload

Attention: Upload file types:. jpg,. png,. jpg,. pdf,. doc,. docx.
Upload file sizes up to 2 MB
