Delixi CDH7R-160/3 Fuse Isolating Switch

Name: Delixi CDH7R-160/3 Fuse Isolating Switch
SKU: CDH7R1603

Brand:

Delixi

Series:

CDH7R

Fuse Specifications:

NT00

On/Off Load Type:

Mixed load switching

Handle Type:

Operating handle inside the cabinet

How It Works:

Frontal Operation

Rated Current:

160A

Poles:

Rated Voltage:

400VAC

Installation:

Base plate installation

Model:

CDH7R-160/3

Order Number:

CDH7R1603

Description:

CDH7R-160/3,3P,bottom panel installation,front operation,160A,mixed load on/off,400VAC,in-cabinet operating handle,NT00

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Delixi
Series：	CDH7R
Fuse Specifications：	NT00
On/Off Load Type：	Mixed load switching
Handle Type：	Operating handle inside the cabinet
How It Works：	Frontal Operation
Rated Current：	160A
Poles：	3P
Rated Voltage：	400VAC
Installation：	Base plate installation

Products with the same attribute : 0

Show details

Series Overview

The isolating switch consists of a base, an upper cover, a middle plate, a push rod, a contact system, and a mechanism. The insulating part is made of glass fiber - reinforced unsaturated polyester film plastic, which improves the product's insulation performance and mechanical strength. The switch adopts a spring - energy - storage, instant - release accelerating closing mechanism and a contact structure that connects and disconnects parallel double breakpoints simultaneously. It cooperates with the isolation structure of the base to achieve a good arc - extinguishing effect, greatly improving the switch's electrical and mechanical performance.
The front of the switch is equipped with a marking window, indicating the on - off state of the contacts. If needed, a rear observation window can be provided to directly observe the on - off state of the contacts, ensuring the reliability and safety of switch operation.
The operating handle can be directly installed on the switch for operation (referred to as in - cabinet operation), or can be operated outside the distribution cabinet through an extended shaft (referred to as out - of - cabinet operation), providing convenient operation.
