ABB ACS355-03E-04A7-2 General purpose inverter ACS355
Brand:
Series:
ACS355
Protection Level:
IP20
Control Panel:
Alternative
Communication Protocol:
Modbus
Voltage Level:
Three-phase 200-240VAC
Rated Power:
0.75KW
Rated Current:
4.7A
Model:
ACS355-03E-04A7-2
Order Number:
3ABD0000058173
Description:
ABB general-purpose inverter ACS355 ACS355-03E-04A7-2, remote display terminal optional, 0.75KW, communication protocol Modbus, IP20, 4.7A, three-phase 200-240VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | ABB | |
| Series： | ACS355 | |
| Remote Display Terminal： | Alternative | |
| Protection Level： | IP20 | |
| Control Panel： | Alternative | |
| Communication Protocol： | Modbus | |
| Voltage Level： | Three-phase 200-240VAC | |
| Rated Power： | 0.75KW | |
| Applications： | Various simple mechanical operations | |
| Rated Current： | 4.7A |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
ABB Mechanical Drives
-
ABB mechanical drives can be quickly installed, parameter - set, and commissioned, thus saving engineering time. They are highly compact and cost - effective. These drives are equipped with advanced intelligence and safety functions, which can meet the production and performance requirements of system integrators, original equipment manufacturers (OEMs), and panel builders, as well as the requirements of end - users in many application fields.
-
In the ABB mechanical drives product portfolio, ACS355 belongs to the compact drive series; it meets requirements such as structural compactness, is optimized for low - power applications, cost - effective, and easy to use. By choosing ABB mechanical drives, the main engine factory can not only obtain all the intelligent functions inside the drives but also enjoy all the additional benefits: the global ABB network. This means that a variety of products and services can support their business.
Applications
- ABB mechanical drives can meet the needs of many machinery applications. This drive is suitable for food and beverage, material handling, lifting, textiles, printing, rubber and plastics, and wood processing applications.
Highlights
- Super - compact drives and consistent design
- Use application macros and panel assistants to achieve quick commissioning
- Standard Safe Torque Off (STO) function
- Perform sensorless vector control for induction motors and permanent magnet motors up to 599 Hz
- Built - in braking chopper
- Provide IP66 products for harsh environments and drives dedicated to solar energy applications
Small Drives, Big Impact
- ACS355 drives are easy to install and set up, which can greatly improve the availability of your equipment. This drive adopts a modular design and supports various fieldbus protocols, so it has flexible connectivity. In addition to a wide range of built - in options (such as different I/O and communication options), it also has a series of external components. No matter where your equipment is located, the local ABB company can provide support for you and your customers.
Flexible Performance
The built - in sequential programming function provides simple logic control, reducing the need for external PLCs. Built - in functions — such as the ability to achieve precise motor speed compensation for stopping and the patented smooth start function for permanent magnet motors — can improve production processes and save costs.
Commissioning is Easy and Fast
Suitable for application - defined pre - set I/O configurations and built - in assistants can accelerate drive commissioning, allowing you to focus on your own business.
Compact and Consistent Design
Compact structure. Similar products from 0.37 - 22kW have a more power - dense and side - by - side installation design, ensuring that the cabinet is suitable for installation in a wide range of machinery applications, thus helping to save space and costs.
Supported Motor Types
The same drive can be used for sensorless vector control of induction motors and for the control of permanent magnet motors without the need for feedback devices.
Products for Specific Applications
Drives suitable for solar energy applications include special built - in functions to protect the pump, which can extend equipment life and ensure the reliability of energy supply. For the main axis application of special high - speed products with adjustable speed controllers, there is no need to use encoders.
Suitable for Harsh Environments
Because there is no need for a dust - proof, dust - proof, and waterproof application design for the outer shell, through NSF - certified IP66/67/69K (UL type 4X protection level) product types can save time and costs.
Connect to Mainstream Automation Communication Networks
Optional fieldbus adapters allow the drive to be directly connected to mainstream industrial automation networks.
Safety
High - level SIL3 integrated Safe Torque Off (STO) function complies with IEC61508, EN 62061, and EN ISO13849 - 1 standards, providing an economical, efficient, and reliable solution for safe equipment maintenance. The safety function can also be used to implement emergency stops in the absence of contactors.
Remote Monitoring
The existing remote monitoring components use the built - in web server and independent data logger to allow you to access the drive safely anytime and anywhere.
Typical Applications
Mixer
- For mixers, the drive can provide high starting torque. The quiet operation mode can adjust the switching frequency of the drive to a higher level after high - torque starting, thus reducing low - frequency noise. The FlashDrop tool can quickly and safely set up multiple drives for the same mixer application.
Conveyor Belt
- Production lines usually have multiple processes, including conveyor belts, which must be efficiently connected to achieve greater productivity. The drive can make the conveyor belt start and stop smoothly, thus reducing mechanical stress and lowering maintenance costs.
Packaging Machine
- Packaging machines usually need drives to achieve the high repeatability and accuracy required for packaging operations. Therefore, ACS355 is very suitable for packaging operations and can also provide good dynamic and static speed control accuracy. Sequential programming allows the drive to execute sequence tasks, thus reducing the need for PLCs. The software configuration includes timers, counters, control points, and motion — all of which can be used in packaging machines.
Filling Line
- During filling, the filling line needs drives to ensure accuracy. ACS355 has good dynamic and static speed control functions and is very suitable for achieving this goal. When it comes to liquids, ACS355 with a high protection level (IP66) is also a good choice.
Bending Machine
- ACS355 has very high static speed control accuracy. When dealing with the wire in the bending machine, it must accurately control the speed of the bending machine to prevent wire breakage. On the other hand, the surface bending machine also needs static speed control accuracy to control the material thickness or tension.
