Schneider ATV-12HU22M2 Universal Inverter ATV12
Brand:
Series:
ATV12
Protection Level:
IP20
Control Panel:
Standard
Communication Protocol:
Modbus
Voltage Level:
Single phase 200-240VAC
Rated Power:
2.2KW
Rated Current:
10A
Model:
ATV-12HU22M2
Order Number:
ATV12HU22M2
Description:
Schneider general purpose inverter ATV12 ATV-12HU22M2, remote display terminal optional, 2.2KW, communication protocol Modbus, IP20, 10A, single phase 200-240VAC
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Schneider | |
| Series： | ATV12 | |
| Remote Display Terminal： | Alternative | |
| Protection Level： | IP20 | |
| Control Panel： | Standard | |
| Communication Protocol： | Modbus | |
| Voltage Level： | Single phase 200-240VAC | |
| Rated Power： | 2.2KW | |
| Applications： | Various simple mechanical operations | |
| Rated Current： | 10A |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
The ATV12 frequency inverter is used for three - phase asynchronous motors with a power range of 0.18 kW to 4 kW.
The ATV12 is very suitable for simple industrial machine applications due to its ready - to - install (complying with plug - and - play principles), compact structure, integration of multiple functions in one, and optional basic panel, making it very convenient. It is an all - purpose device.
Applications in Simple Industrial Machinery:
- Material handling (small conveyors, etc.)
- Packaging (small labeling machines, small bag - making machines, etc.)
- Pump applications (water pumps, centrifugal pumps, circulation pumps, single pumps, and multi - pump stations, etc.) (▲)
- Machines equipped with fans (ventilation or oil - fume extractors, plastic extruders, ovens, boilers, washing machines, etc.)
Applications in Civil Equipment:
- Simple actuators (entrance/exit barriers, rotating billboards, etc.)
- Medical and health fields (medical water pumps, hydro - massage equipment, treadmills, etc.)
- Food and beverage industry (juicers, dough mixers, mixers, etc.)
Other Types of Applications:
- Commercial building industry (air - conditioning air - supply systems)
- Portable equipment applications (mobile machines and small devices with power sockets, etc.)
- Applications traditionally using other solutions:
- (1) Dual - speed motors, DC motors, mechanical transmissions
- (2) Single - phase motors for fans and pumps using mechanical control; The “ATV12 + three - phase motor” solution can adapt the power to the needs of the drive application, thus reducing energy consumption.
Functions
In addition to some common functions, the ATV12 frequency inverter also has the following functions:
- Can switch between local control and terminal control
- Motor control modes: standard, high - performance, and fan/pump
- Preset speeds
- PID regulator
- S - shaped ramp, U - shaped ramp, ramp switching
- Free stop, quick stop
- Jog operation
- Set logic input/output and analog input/output
- Underload and overload protection
- Can view the status of logic inputs on the frequency inverter display screen
- Set parameter display mode
- Fault recording, etc.
Optimized Products
The ATV12 frequency inverter series uses three types of power supplies and is suitable for three - phase asynchronous motors with a rated power of 0.18 kW to 4 kW. There are two standard versions available:
- Frequency inverters with heat sinks, used in normal working environments and cabinets with fan cooling:
- 100... 120V single - phase, 0.18kW to 0.75kW (ATV12H●●●F1)
- 200... 240V single - phase, 0.18kW to 2.2kW (ATV12H●●●M2)
- 200... 240V three - phase, 0.18kW to 4 kW (ATV12H●●●M3)
- Frequency inverters with bases, used for installation on equipment racks, and the surface of the rack should be able to dissipate heat:
- 100... 120V single - phase, 0.18 kW to 0.37kW (ATV12H018F1, P037F1)
- 200... 240V single - phase, 0.18 kW to 0.75 kW (ATV12H018M2, P●●●M2)
- 200... 240V three - phase, 0.18 kW to 4 kW (ATV12H018M3, P●●●M3)
