Siemens 3SU1152-6AA30-1AA0 indicator light
Brand:
Series:
3SU
Installation Diameter:
22mm
Function Type:
-
Color:
yellow
Material:
Metal
Product Type:
LED type
Rated Voltage:
24VAC/DC
Model:
3SU1152-6AA30-1AA0
Order Number:
3SU11526AA301AA0
Description:
product type LED, metal, rated voltage 24VAC/DC, yellow, installation diameter 22mm
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | 3SU | |
| Installation Diameter： | 22mm | |
| Function Type： | - | |
| Color： | yellow | |
| Material： | Metal | |
| Product Type： | LED type | |
| Rated Voltage： | 24VAC/DC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
SIRIUS ACT Buttons and Indicators
- SIRIUS ACT adopts a modular design, which consists of button heads, indicator lights, contact blocks installed on the back of the panel, and LED modules. For the most common application conditions, it can provide complete sets of buttons and indicators composed of button heads or indicator light heads, as well as contact blocks and/or LED modules.
- The integrated buttons and indicators are already equipped with contact blocks and LED modules, and only need to be fixed in the middle.
Standards
- IEC 60947 - 1, EN 60947 - 1
- IEC 60947 - 5 - 1, EN 60947 - 5 - 1
- IEC 60947 - 5 - 5, EN 60947 - 5 - 5 (for emergency stop command devices)
Specifications
SIRIUS ACT can provide four specifications:
- Plastic, 22mm, circular, black
- Metal, 22mm, circular, matte
- Metal, 22mm, circular, bright
- Metal, 30mm, pure flat design, circular, matte
A single button/indicator light consists of the following parts:
- Button head or indicator light head on the front side of the control panel
- Middle seat for fixing on the back side of the control panel
- Up to six contact blocks and/or one LED module (installed on the middle seat), and single contact blocks can be used in a stacked combination
- Various labels for marking/identification
- Can provide integrated indicator lights, buzzers, potentiometers, inductive operation buttons, lever - extended buttons, and indicators. This integrated design has electrical components pre - assembled, only requiring wiring.
Functional Features
Easy to Use
- Both the button head and the middle seat are marked with the installation direction, convenient and easy to use
- The middle seat is installed with a single screw and has a lever - type design, easy to install and remove
- Contact blocks can be used in a stacked manner
Sturdy and Durable
- Protection class IP69K
- LED modules have a service life of up to 100,000 hours
- Mechanical service life can be as high as 1.0×10⁶ times
- The button head has a rubber ring, and the middle seat also has a design to prevent twisting, being firm and durable
High - Quality Communication
- Button boxes directly connect to AS - i or IO - Link communication
- Directly connect to IO - Link, AS - i, or PROFINET communication inside the switch cabinet
Contact Blocks and LED Modules
- Contact blocks can ensure high reliability even when the voltage and current are small (such as 5V/1mA). They are suitable for both electronic control systems and traditional control systems. Normally closed contact blocks have the feature of forced opening.
- Integrated LED modules are used for illumination.
- Both contact blocks and LED modules have connection markings that meet the EN 50013 standard.
Installation of Modules
- For SIRIUS ACT, install the modules (without other accessories) on the middle seat. The middle seats are divided into plastic and metal types, and these middle seats are all equipped with three module installation positions. For lever - operated buttons and selector buttons with four switch positions, middle seats with four module installation positions can be provided.
Interface Types
Module interface types include:
- Screw - type connection
- Cage - clamp connection
- Soldering connection (solder pad 0.8mm x 0.8mm) for assembly on circuit boards
ID Key Operation Buttons
- ID key operation buttons are electronic. The keys have different encodings and can control up to 4 switch positions at most. With 4 different encoded ID keys, 1 - 4 positions can be selected. ID keys can be clearly distinguished by color codes (yellow, blue, red, green, white).
- The differences of ID key operation buttons are:
- Environmentally friendly raw materials
- Traditional series: 1 + 4 non - insulated output terminals
- Series with IO - Link: Can be individually encoded
Operation:
- Insert the ID key and select the position by rotating. Even in the electronic module, the standard key can also be used as an ID key operation button with IO - Link function. The white ID key is not encoded when delivered.
Highlights of SIRIUS ACT
Modern Design
- Beautiful appearance design
- Perfect combination of design and function
Easy to Use
- Simple and intuitive installation method
- One - hand installation
- No special tools required
- Simple panel hole opening, no need to reserve key slots
Sturdy and Durable
- High protection class IP69K
- Used in extreme environments
- The protection class of the whole series is consistent, all reaching IP66/P67/IP69K, convenient for design
Communication
- Can be connected to the most common communication systems (AS - i interface, IO - Link, PROFINET communication)
- Can be simply integrated through TIA - Portal
SIRIUS ACT buttons and indicators can provide the following support for realizing the high - efficiency and energy - saving of the complete system:
- LED technology effectively reduces current consumption
- Long service life
Environmental Conditions
- Buttons and indicator lights have good resistance to aging (KTW 24), specially designed for the application conditions in standard industrial applications and ship equipment.
- The explosion - proof type "intrinsically safe" Exi meets the requirements of ATEX Directive 94/9/EG.
- Meets the safety stop requirements of ISO 13850 standard.
- SIRIUS ACT emergency stop buttons meet the requirements of IEC 60204 - 1 or EN 60204 - 1 standard.
Safety Circuits
- According to the requirements of IEC 60947 - 5 - 1 or EN 60947 - 5 - 1 standard, it needs to have the function of forced opening. Out of consideration for personal safety, the method for correctly opening normally closed switch elements in all safety circuits of the machine shall be clearly defined for electrical equipment, and marked with the identification (⌘) as required by IEC 60947 - 5 - 1.
- When selecting and correctly connecting appropriate fault - safe analysis equipment (such as 3SK11 safety switch equipment, 3RK3 modular safety system or ASIsafe, SIMATIC or SINUMERIK program - compatible devices), the emergency stop button can meet the requirements of EN ISO 13849 - 1 level 4.
- SIRIUS ACT buttons and indicators can be quickly and safely integrated into the AS - i communication system.
Provide the following solutions:
- AS - i interface module
- Safety - type AS - i interface module suitable for emergency stop buttons
- Pre - assembled AS - i interface button boxes, with 1 to 6 single button/indicator lights
IO - Link
- SIRIUS ACT buttons and indicators can be quickly and safely connected to IO - Link, connected through a special IO - Link module.
