TENGEN TGAD56-22D AC/DC24V Yellow indicator light
Brand:
Series:
TGAD56
Installation Diameter:
22.3mm
Function Type:
-
Color:
yellow
Material:
plastic
Product Type:
LED type
Rated Voltage:
24VAC/DC
Model:
TGAD56-22D AC/DC24V Yellow
Order Number:
08100030139
Description:
product type LED type, plastic, rated voltage 24VAC/DC, yellow, installation diameter 22.3mm
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | TENGEN | |
| Series： | TGAD56 | |
| Installation Diameter： | 22.3mm | |
| Function Type： | - | |
| Color： | yellow | |
| Material： | plastic | |
| Product Type： | LED type | |
| Rated Voltage： | 24VAC/DC |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
- This product is suitable for use as command signals, pre-alarm signals, fault signals, and other indication signals in electrical circuits with an AC rated working voltage of 380V and below at 50Hz (or 60Hz), and a DC rated working voltage of 220V and below.
Compliance Standards
- GB14048.5
Ambient Temperature
- Not exceeding +40°C, and the average temperature within 24 hours does not exceed +35°C. The lower limit of the ambient air temperature is -5°C.
Altitude
- Not exceeding 2000m.
Atmospheric Conditions
- When the maximum temperature is +40°C, the relative humidity of the air does not exceed 50%; at lower temperatures, a higher relative humidity is allowed. For example: reaching 90% at +20°C; special measures should be taken for the occasional condensation caused by temperature changes.
Pollution Degree
- Level 3.
Installation Category
- Category II.
Structural Features
- All products in the series use LED chips as the light source, which have low energy consumption, high brightness, low temperature rise, and long service life.
- Wide power supply voltage, can work normally within the range of rated voltage ±15%.
- Vibration-resistant and impact-resistant, can work normally under the vibration conditions of frequency (sine wave) 10 - 2000Hz, 1.5mm, 10g, solving the problems of bulb filament breakage and high maintenance cost, greatly improving the reliability of the product and facilitating users.
- High safety performance, easy to use. The live parts are all embedded in the shell, and the combined screw crimping is used, which is convenient for users and saves wiring time.
- Small size, light weight, good performance.
- The product has a beautiful appearance and diverse varieties. The colors are bright, the lines are soft, and it can play multiple roles such as indication, decoration, and lighting when installed on the equipment.
- Good interchangeability. Due to its novel design, this product can be installed on the mounting hole of φ22.3 + 0.4, which not only meets the matching needs of the exporting country but also meets the maintenance requirements of the original old equipment.
