Phoenix FL SWITCH 1605 M12(2700200) Industrial Ethernet Switch
Brand:
Series:
Non-pipe IP67
Ethernet Interface:
5 M12 sockets, 10/100Mbps
Fiber Optic Interface:
-
Supply Voltage:
24VDC (M12 connector)
Product Type:
Unmanaged switches
Model:
FL SWITCH 1605 M12(2700200)
Order Number:
2700200
Description:
24VDC (M12 connector), Ethernet interface 5 M12 holes, 10/100Mbps, unmanaged switch
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Phoenix | |
| Series： | Non-pipe IP67 | |
| Ethernet Interface： | 5 M12 sockets, 10/100Mbps | |
| Fiber Optic Interface： | - | |
| Supply Voltage： | 24VDC (M12 connector) | |
| Product Type： | Unmanaged switches |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
SF Overview
Unmanaged switches are extremely reliable and easy to maintain, suitable for low-cost and reliable Ethernet networks.
For long-distance or high-interference application scenarios, various types of products with fiber optic interfaces are provided for your choice. You can choose switches that have both electrical ports and SC or ST fiber optic interfaces.
Advantages:
- Speed auto-negotiation and port auto-crossing technology make network creation and expansion easier
- Optional gigabit products are suitable for large-traffic data transmission
- Electrical isolation technology and optional fiber optic output function enable trouble-free operation in industrial environments
Dimensions
| Specification | Details |
|---|---|
| Dimension Drawing | （Figure: Side view (dimensions in mm)） |
| Picture Caption | Side view (dimensions in mm) |
| Width | 30 mm |
| Height | 200 mm |
| Depth | 41 mm |
Environmental Conditions
| Specification | Details |
|---|---|
| Protection Class | IP65
IP66
IP67
|
| Ambient Temperature (Operation) | -40 °C... 70 °C |
| Ambient Temperature (Storage/Transport) | -40 °C... 70 °C |
| Humidity Allowed (Operation) | 10 %... 95 % |
| Humidity Allowed (Storage/Transport) | 10 %... 95 % (No Condensation) |
| Air Pressure (Operation) | 86 kPa... 108 kPa (Up to 2000 Meters Above Sea Level) |
| Air Pressure (Storage/Transport) | 66 kPa... 108 kPa (Up to 3500 Meters Above Sea Level) |
Functions
| Function Specification | Details |
|---|---|
| Basic Functions | Unmanaged switch/Auto-negotiation, complying with IEEE 802.3 standard requirements, store-and-forward switching mode, 2 priorities complying with IEEE802.1p standard requirements, PTCP filter |
| Other Functions | Autonegotiation |
| PROFINET Conformance Class | Conformance-Class A |
| Diagnostic and Status Indicators | LED: US (Power supply voltage), 2 LEDs per Ethernet port (Link and Activity) |
Network Expansion Parameters
| Parameter Specification | Details |
|---|---|
| Topology | Network, star, and bus structures: Any |
| Maximum Cable Length (Twisted Pair) | 100 m |
Power Supply Voltage
| Voltage Specification | Details |
|---|---|
| Power Supply Voltage | 24 V DC (M12 plug-in connector) |
| Ripple | 3.6 Vpp |
| Power Supply Voltage Range | 9 V DC... 32 V DC |
| Typical Current Consumption | 40 mA (Uₛ = 24 V DC) |
| Maximum Current Consumption | 40 mA (Per port + 10 mA) |
| Current Consumption | 40 mA... 80 mA (24 V DC) |
Overview
| Specification | Details |
|---|---|
| Mounting Type | Wall-mounted |
| Type AX | Single unit |
| Net Weight | 281.7 g |
| Housing Material | PBT |
| Material Certificate | High-grade steel (1.4301/1.4016) |
| Precautions | Note: Meet the requirements of internal electrical clearance
When installing on the electrical cabinet, use cable glands to connect to PE. When installing the power cable within the electrical cabinet, use cable glands to connect to PE.
In 2023, installed using cable glands to connect to PE. When the power cable is within the electrical cabinet, use cable glands to connect to PE.
|
| MTTF | 302.5 years (SN 29500 standard type, temperature 25°C, duty cycle 21% (5 days per week, 8 hours per day))
156.52 years (SN 29500 standard type, temperature 40°C, duty cycle 34.25% (5 days per week, 12 hours per day))
40.43 years (SN 29500 standard type, temperature 55°C, duty cycle 100% (7 days per week, 24 hours per day))
|
Standards and Specifications
| Specification | Details |
|---|---|
| Electromagnetic Compatibility | Comply with 2014/30/EU EMC Directive |
| Test Type | Comply with EN 60068-2-27/IEC 60068-2-27 Impact Standard |
| Test Result | Operation: 30g, 6 ms duration test, 5g, 30 ms duration test |
| Test Type | Comply with EN 60068-2-27/IEC 60068-2-27 Impact Standard |
| Test Result | Comply with EN 60068-2-6/IEC 60068-2-6 Vibration Standard |
| Test Type | Operation/Storage/Transport: 5g, 150 Hz, Standard 3 |
| Test Result | Comply with IEC 60068-2-32 Free Fall Test of Enclosure |
| Test Result | 0.5 m |
| Test Type | Immunity complies with IEC 61373, EN 61373 standards |
| Test Result | Class 1, Category B |
| Emission Interference | EN 61000-6-4 |
| Immunity to Interference | EN 61000-6-2 |
| Connection Compliance Standard | CUL |
