ABB CR-U024AC3 intermediate relay

Name: ABB CR-U024AC3 intermediate relay
SKU: 10050204

Brand:

ABB

Series:

Contact Type:

3C/O

Control Voltage:

24VAC

LED Indicator:

Without light

Rated Current:

10A

Product Type:

Universal type

Model:

CR-U024AC3

Order Number:

10050204

Description:

ABB intermediate relay CR-U024AC3, without light, control voltage 24VAC, contact type 3C/O, rated current 10A, general purpose

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	ABB
Series：	CR
Contact Type：	3C/O
Control Voltage：	24VAC
LED Indicator：	Without light
Rated Current：	10A
Product Type：	Universal type

Products with the same attribute : 0

Show details

Series Overview

CR-P PCB Relay

9 types of coil voltages
- DC: 12V, 24V, 48V, 110V
- AC: 24V, 48V, 110V, 120V, 230V
Output contacts:
- 1c/o (16A)
- 2c/o (8A), optional pure gold contacts
Logic/standard base
Contact material contains no cadmium
Base width: 15.5mm
Pluggable function modules:
- Reverse polarity protection/Freewheeling diode
- LED indication
- RC components
- Overvoltage protection

CR-M Micro Relay

12 types of coil voltages
- DC: 12V, 24V, 48V, 60V, 110V, 125V, 220V
- AC: 24V, 48V, 60V, 110V, 120V, 230V
Output contacts:
- 2c/o (12A)
- 3c/o (10A)
- 4c/o (6A), optional pure gold contacts, LED and freewheeling diode
Integrated test button, manual operation and locked output contacts (blue = DC, orange = AC) can be removed as needed
With/without LED indication
Logic/standard base
Contact material contains no cadmium
Base width: 27mm
Pluggable function modules:
- Reverse polarity protection/Freewheeling diode
- LED indication
- RC components
- Overvoltage protection

CR-U General - Purpose Relay

10 types of coil voltages
- DC: 12V, 24V, 48V, 110V, 125V, 220V
- AC: 24V, 48V, 60V, 110V, 120V, 230V
Output contacts:
- 2c/o (10A)
- 3c/o (10A)
Integrated test button, manual and locked output contacts (blue = DC, orange = AC) can be removed as needed
With/without LED indication
Contact material contains no cadmium
Base width: 38mm
Pluggable function modules:
- Reverse polarity protection/Freewheeling diode
- LED indication
- RC components
- Overvoltage protection
- Multi - function time module

CR-MX General - Purpose Micro Relay

7 types of coil voltages
- DC: 12V, 24V, 48V, 110V
- AC: 24V, 110V, 230V
Output contacts:
- 2c/o (7A)
- 4c/o (5A)
With/without LED indication
Contact material contains no cadmium
Base width: 30.3mm
Pluggable function modules:
- Reverse polarity protection/Freewheeling diode
- LED indication
- RC components
- Overvoltage protection

CR-S Plug - in Intermediate Interface Relay

9 different rated control voltages:
- DC type: 5V, 12V, 24V
- AC/DC type: 12V, 24V, 48V, 60V, 110V, 230V
Output: 1c/o contact (6A), standard and gold - plated contacts
All bases come with LED
Contact material contains no cadmium
Standard ultra - thin relay (5mm), base (6.2mm) and accessories
Screw and spring terminal blocks
Short - circuit bars (red, black, blue), identification cards and shields are available as accessories
