Siemens LZX:PT370024 intermediate relay
Brand:
Series:
LZX
Contact Type:
3C/O
Control Voltage:
24VDC
LED Indicator:
Without light
Rated Current:
10A
Product Type:
Plug-in type
Model:
LZX:PT370024
Order Number:
LZX:PT370024
Description:
Siemens intermediate relay LZX:PT370024, without light, control voltage 24VDC, contact type 3C/O, rated current 10A, plug-in type
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Siemens | |
| Series： | LZX | |
| Contact Type： | 3C/O | |
| Control Voltage： | 24VDC | |
| LED Indicator： | Without light | |
| Rated Current： | 10A | |
| Product Type： | Plug-in type |
Products with the same attribute : 0
Show details
Series Overview
Series Overview
With Plug - in Relay
- Plug - in relay couplers can be provided as complete sets, as well as individual modules for self - assembly or as spare parts. This series is divided into three types: RT, PT, and MT.
Applications
- As coupling relays, used to achieve
- Electrical isolation between the field and the input and output of electronic control devices
- Contact amplification
- Breaking small loads
- As voltage conversion switches
Advantages
- Adopt innovative push - in spring - type terminals, allowing wiring without tools and achieving anti - vibration connections
- Logic isolation base, convenient for wiring
- Tested AC - 15 and DC - 13 breaking capacity
- Available coil voltages: 24 V DC, 24 V AC, 115 V AC, 230 V AC
- Hard - gold - plated relay contacts, which can match electronic control components
Configuration Information
- The test rod of the PT relay has no locking mechanism. If the test rod is further pressed and moved 90°, the two small engaging pieces will break, and the test rod can be placed in the locked position. When using a plug - in relay with 60 Hz alternating current, the smaller response value needs to be increased by 10%, and the power loss will be slightly reduced.
Logic Isolation
- The contact element connectors and coil connectors are arranged on different sides. For example, the contact elements are located at the top, and the coils are located at the bottom. This improves the transparency of wiring. Logic isolation is not a necessary safety isolation.
Safety Isolation
- Through safety isolation, fully prevent voltage from coupling from one circuit to another. (DIN VDE 106 Part 101)
