TGM1-630 Prepaid Shunt AC220V Molded Case Circuit Breaker Accessories

Name: TGM1-630 Prepaid Shunt AC220V Molded Case Circuit Breaker Accessories
SKU: 150005891

Brand:

TENGEN

Series:

TGM1

Attachment Name:

Prepaid shunt release

Model:

Accessories TGM1-630 Prepaid Shunt AC220V

Order Number:

150005891

Description:

TENGEN molded case circuit breaker accessories TGM1-630 prepaid shunt AC220V

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	TENGEN
Series：	TGM1
Attachment Description：	With prepaid shunt release, rated control power supply voltage 220VAC
Attachment Type：	-
Attachment Name：	Prepaid shunt release

Products with the same attribute : 0

Show details

Series Overview

Internal Accessories

Undervoltage Release (UVR)
- Rated operational voltage (Ue): AC 230V, AC 400V.
- The undervoltage release shall operate when the voltage drops (even slowly) to within the range of 35% to 70% of its rated voltage.
- When the supply voltage is below 35% of the undervoltage release voltage, the undervoltage release shall prevent the circuit breaker from closing.
- When the supply voltage is equal to or greater than 85% of the rated voltage, it shall ensure the circuit breaker can close.
Special Reminder: For a circuit breaker equipped with an undervoltage release, the circuit breaker can only be opened and closed normally when the undervoltage release is energized at its rated voltage. Otherwise, the circuit breaker may be damaged.
Shunt Release (SHT)
- Rated control supply voltage (Us): AC 230V, AC 400V, DC 24V, AC 24V.
- The circuit breaker shall trip within 70% to 100% of the rated voltage.
- Note: When the DC 24V voltage specification is selected, the rated current of the control circuit must reach 5A.

Auxiliary Contact (AX)

Frame Rating	Conventional Thermal Current Ith (A)	Rated Current Ie (A) at AC 400V	Rated Current Ie (A) at DC 230V
Inm ≤ 250A	3	0.3	0.15
Irm ≥ 400A	3	3	0.2

Alarm Contact (AL)
- The alarm contact does not operate during normal opening/closing operations of the circuit breaker. It only operates (changes state) after a trip (or fault trip).
- Specifically: Normally Open (NO) contacts close, and Normally Closed (NC) contacts open.
- After the circuit breaker is reset, the alarm contact returns to its original state.

Rachel

Industrial Control Sales Specialist: Focuses on delivering high-performance, cost-effective industrial control products. Offers end-to-end one-stop procurement support—covering rapid quotation, streamlined order fulfillment, and responsive after-sales service—to simplify clients’ procurement processes. Email: Anthony@icxsg.com

We offer competitive product pricing. For fast support, send your email, phone, address, and the product model & quantity you want—we’ll reach out quickly!
