Delixi CDM3L-125S/2300 125A 30-100-300MA Molded Case Leakage Protection Circuit Breaker
Brand:
Series:
CDM3L
How It Works:
Manual
Frame Current:
125A
Protection Function:
LI
Wiring Method:
Front panel wiring
Poles:
2P
Installation:
Fixed
Breaking Capacity:
35KA
Model:
CDM3L-125S/2300 125A 30-100-300MA
Order Number:
M3L125S12523KS
Description:
Delixi molded case leakage protection circuit breaker CDM3L-125S/2300 125A 30-100-300MA, fixed, manual, 35KA, front wiring, 2P, frame current 125A
Product parameters
| Product attributes | Attribute value | Filter product attributes |
|---|---|---|
| Brand： | Delixi | |
| Series： | CDM3L | |
| How It Works： | Manual | |
| Frame Current： | 125A | |
| Protection Function： | LI | |
| Wiring Method： | Front panel wiring | |
| Poles： | 2P | |
| Installation： | Fixed | |
| Breaking Capacity： | 35KA |
Products with the same attribute : 0
Show details
Series Overview
CDM3 & CDM3L Molded Case Circuit Breakers
Product Overview
Compliant Standards
● GB/T 14048.1 General Rules
● GB/T 14048.2 Circuit-breakers
● IEC 60947-1 General Rules
● IEC 60947-2 Circuit-breakers
● Pollution Degree: CDM3 series products operate in Pollution Degree 3 environments as defined by standards IEC 60947-1 and IEC 60664-1 (industrial environments).
Resistance to Humidity and Heat
● Dry cold, dry heat, humid heat ambient temperature
● The CDM3 series can operate continuously under normal environmental and operating temperature conditions ranging from -5°C to 40°C.
● If the operating ambient temperature exceeds 40°C (or 60°C for motor protection), refer to the temperature derating coefficient table for use.
● Storage temperature range: -20°C to 70°C.
Altitude
● Normal operating installation altitude does not exceed 2000m.
● If installation at an altitude exceeding 2000m is required, changes in dielectric strength and the decrease in air cooling capacity must be considered. Refer to the altitude derating coefficient table for use.
Humidity
● Normal operation requires:
● Relative humidity of the surrounding air must not exceed 50% at an ambient temperature of +40°C. At lower temperatures, higher relative humidity is permissible.
● The monthly average relative humidity of the most humid month is 90%.
● The impact of condensation forming on the product surface on product performance must be considered.
Reliable Contact Indication with Isolation Function
● All CDM3 series molded case circuit breakers comply with the isolation requirements defined in IEC standard 60947-2.
● The isolation position corresponds to the "0" (OFF) position.
● The operating handle can only indicate the "OFF" position when the contacts are genuinely open.
● The reliability of the contact indication system is not affected by the use of a rotary handle or an electrical operating mechanism.
● Testing confirms the isolation function guarantees:
● Mechanical reliability of the contact indication system.
● No leakage current.
● Adequate overvoltage withstand capability between the line and load terminals.
Protection Class (IP Rating)
● Circuit breaker body: IP20.
● Circuit breaker installed in a switchgear panel:
● With toggle handle: IP40.
● With electrical operating mechanism: IP40.
