DZ15LE-100/2901T 100A 50MA Molded Case Leakage Protection Circuit Breaker

Name: DZ15LE-100/2901T 100A 50MA Molded Case Leakage Protection Circuit Breaker
SKU: 01020010360

Brand:

TENGEN

Series:

DZ15LE

How It Works:

Manual

Frame Current:

100A

Protection Function:

Wiring Method:

Front panel wiring

Poles:

Installation:

Fixed

Breaking Capacity:

5KA

Model:

DZ15LE-100/2901T 100A 50MA

Order Number:

01020010360

Description:

Molded case leakage protection circuit breaker DZ15LE-100/2901T 100A 50MA, fixed, manual, 5KA, front wiring, 2P, frame current 100A

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	TENGEN
Series：	DZ15LE
How It Works：	Manual
Frame Current：	100A
Protection Function：	LI
Wiring Method：	Front panel wiring
Poles：	2P
Installation：	Fixed
Breaking Capacity：	5KA

Products with the same attribute : 0

Show details

Series Overview

Outline

The DZ15LE series Residual Current Circuit Breaker (hereinafter referred to as the RCCB) is suitable for circuits with an AC frequency of 50Hz, rated voltage of 220V or 380V, and rated current up to 100A, providing residual current protection. It can also be used to prevent fire hazards caused by earth fault currents resulting from equipment insulation damage. Furthermore, it can protect lines from dangers such as overload and short circuit, and serve for the infrequent switching of lines. The derived transparent-shell RCCB in this series features a cover made of new, high-temperature-resistant, high-strength polycarbonate material, allowing for visual confirmation of contact status (open/closed). It is widely used in temporary power supply locations such as construction sites.
Compliant with Standard: GB14048.2.

Normal Service and Mounting Conditions

The altitude of the installation site shall not exceed 2000m.
Ambient Air Temperature:
- The upper limit of the ambient air temperature shall not exceed +40°C, and the lower limit shall not be lower than +5°C.
- The average value of the ambient air temperature over any 24-hour period shall not exceed +35°C.
Atmospheric Conditions:
- The relative humidity of the atmosphere shall not exceed 50% at the maximum ambient temperature of +40°C. A higher relative humidity is permissible at lower temperatures. The monthly average maximum relative humidity is 90%, with the monthly average minimum temperature for that month being +25°C, taking into account condensation occurring on the product surface due to temperature changes.
Installation Category: III.
Mounting Conditions:
- Mount in a location free from impact, vibration, and rain/snow ingress.
- The upper terminals connect to the power supply side; the lower terminals connect to the load side.
- The inclination angle relative to the vertical plane shall not exceed 5°.
Pollution Degree: 3.
The external magnetic field at the RCCB installation site shall not exceed 5 times the Earth's magnetic field in any direction.

Standards Compliance

GB14048.2

Certifications Obtained

Rachel

Industrial Control Sales Specialist: Focuses on delivering high-performance, cost-effective industrial control products. Offers end-to-end one-stop procurement support—covering rapid quotation, streamlined order fulfillment, and responsive after-sales service—to simplify clients’ procurement processes. Email: Anthony@icxsg.com

We offer competitive product pricing. For fast support, send your email, phone, address, and the product model & quantity you want—we’ll reach out quickly!
